China Manufacturer ZX Compound Cone Crusher For Mining

1、China manufacturer zx compound cone crusher for mining 2、Type:Secondary CrushingInput Size:80mm-300mmProcessed Materials: Limestone, Granite, Gabbro, Basalt, River Stone, Coal Gangue, Quartz, Diabase,Iron Ore, Copper Ore, Zinc Ore, Manganese Ore, etc. (for Hard Stone).Applications:Aggregates Shaping, Mechanism sand, Bituminous Concrete, Metal Mine, Sand Making, Chemical, Road, RailwayCapacity:80-610TPHDelivery Detail: After the payment, according to customer demandPackaging Details:International standardInstallation:Engineer assignedColor:As your requestMotor Type:AC Motor3、Product  Description:Compound Cone Crusher was widely used in mining, concrete factory, sand stone making, etc. This best sell used in mining cone crusher not only improves the production capacity and crushes efficiently, but also widens the applying area, the hardness of materials range from limestone to basalt . The machinery's pressure resistance strength is under 350Mpa.Compound Cone Crusher has been developed to crush high or medium hardness material, such as iron ore, copper ore, limestone, quartz, granite, and sand stones, etc. And it is used in metallurgical, construction, road building, chemical, silicate Industries. The cone crusher has the advantage of reliable construction, high prod activity, easy adjustment and less cost in operation.The spring release system of crusher acts an overload protection system that allo ws tramp to pass through the crushing chamber without damage to the crusher, use dry oil, water, two kinds of sealed formation. Cone crusher made plaster stone and engine oil separated, assured reliable performance. The types of crushing chamber depend upon the size of feed and fineness of the crushed product. The standard type is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head is applied to fine crushing.4、Working Principle:When working the rotation of the motor through pulley or coupling, drive shaft and the conical portion of the eccentric force moving around the circle next to a fixed point for rotating pendulum movement, so that the cone crusher crushing wall sometimes near and sometimes off the solid adjustment sleeve mounted on rolling acetabular wall surface, the ore in the crushing cavity constantly under attack, pressing and bending and crushing ore.During operation, the motor of the cone crusher drives the eccentric shaft shell to turn around through a horizontal axle and a pair of bevel gear. The axle of crushing cone swings with the force of eccentric shaft shell so that the surface of the crushing wall is close to the roll mortar wall from time to time. In this way, the ores and rocks will be pressed and crooked and crushed.Bevel gear drive motor through eccentric rotation, so crushing cone make swing movement. crushing cone sometimes close and sometimes away from the fixed cone, to complete the crushing and nesting. Support sleeve and frame body connection is pressed by spring, when the piece of metal and other objects which can not be broken fall within the crusher , compressive deformation of the spring discharge foreign objects, to achieve safety and prevent damage to the machine.5、Product  Features:1. The compound cone crusher is of high reduction ratio, high performance, low power consumption, and uniform size products.2. Stable running performance and easy operation;3. High quality wear-resistant parts reduce operating cost;4. Long life and large application.;5. The rotation had been improved to the limit based on the old spring   cone crusher; the utilization of electric energy becomes more   efficient, reduced the cost.6.High crushing ratio, large main shaft eccentricity, larger feeding opening, smaller discharging opening, so the capacity will become more maximization.6、Product  Specifications:ModelCavity TypeStroke(mm)Max.Feeding Size(mm)Discharging Opening Adjusted Scope(mm)Capacity(t/h)Motor Power(kw)Weight(t)ZX1650C2-DCoarse3430035-65280-61025035ZX1650C-DCoarse3426030-602665-58025035ZX1650Z-DMedium Coarse3424025-60240-55025035ZX1650S-XFine2813020-45180-35025035ZX1400C-DCoarse3023530-60210-53022025ZX1400Z-DMedium Coarse3021525-50200-50022025ZX1400Z-XMedium Coarse2518022-45180-47522025ZX1400S-XFine2510019-40130-26022025ZX1200C-DCoarse2218019-50110-25013216ZX1200S-Xfine158016-4080-18013216Equipped with experienced and qualified personnel professional in researching, developing and manufacturing high quality china manufacturer zx compound cone crusher for mining and a productive factory, Zhongxin Heavy Industrial is acknowledged as one of the largest and leading china manufacturer zx compound cone crusher for mining manufacturers and suppliers. Come and get our machines at reasonable price.
