Gray Color Hammer Powder Coating
Surface Finish Options Overview
![]()
Basic Info.
| item | information |
|---|
| Model NO. |
Hammer Tone Finish Powder Coating |
| Method |
Spray |
| Main Raw Material |
Polyester Resin |
| Certification |
ISO14001. RoHS, ISO9001 |
| Colors |
Ral Code |
| Finish |
Wrinkle/Sanded/Netted/Crackle/Crocodile/Smooth/etc |
| Used Filed |
Steel, Iron, Copper and Other Metals |
| Certificates |
ISO, RoHS and SGS |
| Appearance |
Powder |
| Components |
Epoxy Resin |
| Level |
Finish Coat |
| Substrate |
Any Metal |
| Formation Mechanism |
Conversion Type |
| Application |
Electrostatic Spray Gun/Tribo, We Have Our Own Powder Coating Factory |
| Certificate |
ISO14001. RoHS, ISO9001 |
| Gloss |
Glossy, Semi Glossy or Matt |
| Origin |
China |
Product Detail
| Attribute | Details |
|---|
| Type |
Epoxy and Polyester Powder Coating |
| Color |
RAL and PANTONE or customized |
| Surface Finish |
smooth / sandy / wrinkle / metallic / chrome / wood / hammer / glitter and customized |
| Glossy Level |
High glossy/semi glossy/matt |
| Coverage |
High glossy/semi glossy/matt |
| Film Thickness |
50~90μm |
| Specific Gravity |
1.2~1.9 per CBM |
| Application |
Construction aluminum profile, advertisement board, outdoor lamps, highway guardrail, road fence, outdoor metal furnitures, lamp pile, crust of air conditioner, agricultural equipment or can be used on the surface coating of other metal work that require good performance in the environment of high-intensity ultraviolet ray. |
Application recommendation
| Recommendation | Details |
|---|
| Spray Voltage |
60KV---80KV (70KV is suggested for auto coating line) |
| Spray Pressure |
0.05~0.5MPa (1.5~0.2Kg/m² is suggested for auto coating line) |
| Spray Distance |
10-15cm |
| Curing Temperature/Time |
Standard curing temperature 200℃ in 10~15mins, for large object, curing time up to 15mins |
Storage Stability
Store in ventilated, dry, clean room, temperature < 25℃
Away from direct sunlight, fire, heat
For best performance, use within 1 year
