Agricultural machinery powder Coating
Brief description
Made with saturated polyester resin and curing agent such as TGIC or HAA as the main base material
Features
Excellent mechanical properties.
Outstanding weather resistance.
Application areas
Suitable for coating of products exposed to outdoor for a long time, including:
- Communication base stations
- Mechanical equipment
- Household appliances
- Architectural aluminum profiles
- Traffic facilities
- Sports stadium facilities
- Garden facilities, etc.
Product series
Standard weather-resistant and ultra-high weather-resistant products.
Various gloss and color options.
Various surface effects: flat, sand grain, wrinkle, metal effect and mixed color.
Some products have passed Qualicoat Class 1 Certification.
Technical parameters
Powder performance
Specific gravity: 1.1~1.8g/cm³
Mechanical properties
| Test items | Test standards | Performance indicators |
|---|---|---|
| Pencil hardness | GB/T6739-1996 | >=H |
| Adhesion | GB/T9286-1998 | Grade 0 |
| Bending | GB6742-86 | Φ3mm |
| Impact | GB/T1732-93 | 50kg.cm |
| Cupping | GB9753-88 | >6mm |
Corrosion resistance
| Test items | Test standards | Performance indicators |
|---|---|---|
| Salt spray resistance | GB/T1771-91 | No change in coating after 1000 hours, unilateral corrosion at scratches ≤ 2mm |
| Moisture and heat resistance | GB/T1740-79 | >1000 hours slight loss of gloss, ≤1 level |
| Light aging test ASTM G154 QUV 0.78w/m² @340nm 500H | Gloss retention ≥80% | |
Note: The above parameters are laboratory data and are for reference only. The actual indicators are related to factors such as customer environment, equipment, materials, pretreatment, and spraying process.
Application conditions
Pretreatment: phosphating, chromating
Coating: Suitable for corona electrostatic spraying, friction electrostatic spraying, electrostatic fluidized bed spraying, etc.
Curing conditions:
200℃@10 minutes
180℃@15 minutes
Can also be designed according to customer needs
Packaging
Carton packaging.
Net weight 20kg/box.
Lined with polyethylene plastic bag.
Storage conditions
- Store in a dry and ventilated room below 30℃.
- Avoid direct sunlight.
- Under this condition, the powder can be stably stored for 12 months.
- Can be retested after expiration, and can still be used if it meets the requirements.
Safety and health
- All raw materials of powder coatings do not contain toxic substances.
- No toxic gas will be released during baking.
- Avoid inhalation of dust during use.
- Operators should wear dust masks.
- Minimize long-term contact between skin and powder.
- Paint attached to the skin can be washed with soap.
