EE pure epoxy powder coating
Surface Finish Options Overview
Product description
Made with epoxy resin as the main raw material, it has excellent chemical resistance and mechanical properties.
Application areas:
Suitable for coating metal products with high requirements for corrosion resistance, electrical insulation and flexibility. It is generally not recommended to be used directly for surface coating of various outdoor products.
Physical properties:
1. Specific gravity: 1.2-1.8 (depending on color and gloss)
2. Storage: Below 25℃, in a dry environment, it can be stored for 6 months if the packaging is intact.
3. Packaging: 15 kg/box, carton packaging, lined with two layers of polyethylene inner bags.
Coating performance:
| Spraying area | 8-12 m2/Kg, film thickness 70μm (100% powder usage rate) | |
| Adhesion | GB/T 9286 | Grade 0 |
| Impact | GB/T 1732 | 50cm |
| Cupping test | GB/T 9753 | ≥ 6 mm |
| Bending test | GB/T 6742 | ≤ 3 mm |
| Pencil hardness | GB/ 6739 | ≥ H |
| Salt spray test | GB/T 1771 | 1000 h passed |
| Moisture and heat resistance | GB/T 1740 | 1000 h passed |
Application instructions:
Surface treatment: Treat according to the substrate and required performance
Spraying: electrostatic gun or friction gun
Film thickness: 60-70 um
Curing conditions: Workpiece temperature/time: 140-200℃ x 15 minutes (depending on the specific product)
Health and safety:
This powder coating is a non-toxic product, but dust should be avoided during use. Operators are advised to wear appropriate dust masks and glasses. If possible, try to avoid long-term contact between skin and powder coating.
Safety and Protection
All dust is irritating to the respiratory system, so avoid inhaling dust and steam generated during curing. Take measures to avoid skin contact. If contact is necessary, wash the skin with water and soap. If contact with the eyes, wash immediately with clean water and seek medical attention in time. Avoid the deposition of dust and powder particles on the surface and dead corners. Tiny organic particles will ignite and explode under static electricity. All equipment must be grounded to prevent static electricity.
