TJH-3 Column Type Load Cell
Wide range, strong anti-overload capability. Widely used in pharmaceutical and chemical, coal metallurgy, electronic truck scales, railway scales, storage scales, tanks and other large tonnage measuring equipment.
Specifications of TJH-3 Column Type Load Cell
|
Technical Parameter |
|
|
Rated Load |
150~3000 kN |
|
Comprehensive Precision |
|
|
Sensitivity |
|
|
Creep |
±0.05% FS/30min |
|
Zero Output |
±1% FS |
|
Temperature Effect On Zero |
±0.03% FS/10℃ |
|
Temperature Effect On Output |
±0.03% FS/10℃ |
|
Operating Temperature Range |
-20~+65 ℃ |
|
Input Resistance |
380±10 Ω |
|
Output Resistance |
350± 3 Ω |
|
Insulation Resistance |
＞5000 MΩ |
|
Safe Load Limit |
150% FS |
|
Bridge Voltage |
Reference 10V DC |
|
Material |
Alloy Steel |
|
Load Cell Mode Of Connection |
Input+: Red |
|
Input-: Black |
|
|
Output+: Green |
|
|
Output-: White |
|
Tianguang Sensor provides rocker column load cell,load cell for tank weighing system, bending beam load cell, load cells for saleand etc. Contact us toknowmoreor buy load cell.
