45 Degree Flammability Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
Standard
- ASTM D1230: Flammability of Apparel Textiles (45° Inclined Method)
- CFR 16 Part 1610: Flammability of Clothing Textiles (Federal Standard)
- GB/T 14644: Textiles – Burning Behavior – 45° Test Determination of Flame Spread Rate
- FTMS 191-5908: Flammability of Textiles (Federal Test Method Standard)
- CAL TB 117: Flame Resistance of Upholstered Furniture Filling Materials
- NFPA 702: Field Flame Test for Textiles and Films
Product Advantages
- Automated Precision: Built-in control system with automatic ignition, timer (0.1s accuracy), and reset for consistent testing.
- Adjustable Flame Control: Standard flame height (16mm) with calibrated burner for reliable results.
- Standardized Accessories: U-shaped sample holder (152mm × 38mm), bristle device, and flame gauge ensure compliance.
- Multi-Industry Application: Tests textiles, toys, soft furniture, and apparel for flame retardancy.
- Data-Driven R&D: Provides quantitative data for material innovation and quality acceptance.
- Safety Compliance: Meets ASTM, ISO, and federal standards, reducing export certification barriers.
Product Features
- 45° Inclined Testing: Simulates real-world flame spread angles for accurate flammability classification.
- Smart Touch Interface: Integrated printer for real-time report generation and data storage.
- High-Precision Flow Meter: Ensures stable flame height (16mm ±1mm) and pressure control.
- Ventilation System: Rear vent holes (φ12.7mm × 11) and top exhaust (φ12.7mm × 16) optimize airflow.
- Sample Fixation: U-type clamp with knob adjustment for specimen thickness (45° tilt angle).
- Durable Construction: Stainless steel burner (26# syringe needle) and corrosion-resistant components.
Technical Parameters
| Parameter | Specification |
|---|---|
| Operation Interface | Smart Touchscreen (Built-in Printer) |
| Exhaust Vent (Top) | φ12.7 mm × 16 |
| Observation Window | Transparent (Lucency) |
| Rear Vent Holes | φ12.7 mm × 11 |
| Standard Flame Height | 16 mm (Adjustable) |
| Sample Holder | U-Type, 205 mm × 76 mm (Frame: 152 mm × 38 mm) |
| Ignition Time | 1 s (Adjustable) |
| Sample Rack Adjustment | Knob Control (Thickness Adaptive) |
| Specimen Tilt Angle | 45° |
| Burner Type | 26# Standard Syringe Needle |
| Burner Dimensions | 368 mm (L) × 216 mm (D) × 356 mm (H) |
| Dimensions (L×W×H) | 420 mm × 260 mm × 526 mm |
| Weight | 35 kg |
| Power Supply | AC 220V ±10%, 50Hz |
| Burn Timer Accuracy | ±0.1 s |
