Flame Spread Index Tester
The Flame Spread Index Tester is designed to evaluate the flame propagation characteristics of wall and ceiling lining materials. You can measure the material’s flame spread index (FSI) by exposing samples to a controlled tubular burner with a heat output of 530 J/s and monitoring the flame development over time. This tester allows you to assess fire performance accurately according to international and national standards, providing critical data for building safety, material development, and regulatory compliance.
Standards
This tester conforms to the following international and national standards:
GB/T 8624‑2012 — Classification of burning behavior of building materials and products (Flame spread index basis)
GB/T 2406.2‑2009 — Plastics combustion test, vertical burning method
GB/T 2408‑2008 — Plastics combustion test, horizontal burning method
GB/T 27904‑2011 — Flame spread test for interior decoration materials
GB/T 16172‑2007 — Determination of heat release rate and total heat release (Cone calorimeter method)
ISO 5658‑2 — Determination of flame spread index, Part 2: Small flame spread test
ISO/TR 9705‑2 — Room corner flame spread test, Part 2: Material performance evaluation
ISO 5660‑2 — Heat release rate, smoke production, and mass loss, Part 2: Flame spread method
ISO 5660‑4 — Heat release and smoke testing for automotive interior materials
ASTM E162 — Surface flammability: smoke density and flame spread
ASTM E648 — Flame propagation of carpet materials
UL 94 — Plastic material flammability: vertical and horizontal burning tests
BS 6853:1999 — Railway vehicle material flame spread, smoke density, and toxicity evaluation
BS 476‑6:1989 + A1:2009 — Fire performance test of building materials, Part 6: Small flame spread method
Parameters
| Parameter | Specification |
|---|---|
| Dimensions | 950 × 600 × 870 mm |
| Weight | 105.5 kg |
| Heating Devices | 2 × 1000 W quartz heaters providing thermal radiation |
| Burner Type | T-shaped tubular burner |
| Sample Holders | 3 types, stainless steel wrapped |
| Thermocouples | Continuously measure temperature difference between chimney and room |
| Power Output Control | Automatic adjustment according to test timeline |
| Data Acquisition | Computer-based, report generation |
