Large - Scale Bending Tester STD - FB2 - L，ASTM D 5342 Automotive Large Bending Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
TheLarge Bending Tester accurately and quickly measures factors related to curvatures in small bending moments (bending hardness and recoverability). Adding to the small area available with conventional models, the STD-FB2-L enables measurements that were not previously possible, such as large bending moments and bending rigidity of thick sheet material and composites (products) made from multiple materials. The device also offers excellent data reproducibility in addition to easy measurement.
The tester has been put to use in a variety of industries, including the automotive industry.
Standard
GB/T 2679.3. GB/T 23144. ISO 5628. ISO 2493. ASTM D 5342
Features
Measure hardness and recoverability when bending paper, non-woven fabric, and cloth through pure bending tests.
Measure treatment differences (such as flexible processing surface treatment).
Hardness and recovery capabilities when bending can be read instantly, allowing for simple data analysis.
Measured values are obtained using a power meter with sensitivity matching that of a fingertip, so results are consistent with sensory evaluations.
Specification
| Product Name | Large bending Tester |
| Dimensions (W×D×H) *approx. | Measuring unit: 430×370×990 mm Amplifier: 180×400×400 mm |
| Weight *approx. | Measuring unit: 80 kg Amplifier: 10 kg |
| Power supply, Frequency | 100VAC, 50/60Hz |
| Interface | STD-USB (optional) PC (optional)*1 Data logger output terminal |
| OS | Windows 7/8/8.1/10 |
| Sample size | 200×200 mm (standard) Thickness: 15 mm (max.) |
