Adhesion Strength Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The instrument is suitable for quantitative evaluation of adhesion and mechanical strength in a wide range of materials and bonded structures, including:
T-peel strength measurement of laminated materials
180° peel strength testing of adhesive joints
Tensile strength testing of bonded or flexible materials
Tear resistance testing of films, textiles, and papers
Surface adhesion force evaluation of coatings and bonded layers
Typical test samples include:
Adhesive tapes and laminates
Films, sheets, and flexible packaging materials
Paper, paperboard, and coated paper products
Textiles and nonwoven fabrics
Bonded polymer and composite materials
Standards
JIS L 1066 (Testing Methods for Woven Fabrics)
JIS L 1085 (Testing Methods for Nonwoven Fabrics)
JIS L 1086 (Testing Methods for Textile Products)
JIS P 8139 (Determination of Adhesion and Peel Strength of Paper and Board)
Parameters
| Parameter | Specification |
|---|---|
| Measurement range | Load cells available: 0–100 gf, 0–2000 gf |
| Traveling speed | Clamp traveling speed: 50–500 mm/min |
| Measurement speed | Opposing clamp speed: 100–1000 mm/min |
| Travel distance | Stroke per clamp: 150 mm |
| Specimen size | Maximum: 200 mm × 75 mm |
| Output signal | 0 to ±5 V (within ±0.05% FS) |
| Frequency response | 2 kHz / −3 dB |
| Operating environment | Temperature: 0–50 °C |
| Relative humidity: ≤85%, non-condensing | |
| Power supply | AC 100 V, 50/60 Hz |
| Dimensions | W 630 mm × D 310 mm × H 350 mm |
Features
Wide measurement capability from very low to relatively high adhesion forces
Supports multiple test modes, including T-peel, 180° peel, tensile, tear, and surface adhesion tests
Desktop-type design suitable for laboratory and on-site testing
Portable structure allows convenient measurements in different locations
Simple zero balance and calibration procedures enable quick and intuitive operation
Stable opposing-motion mechanism ensures consistent and repeatable test results
在线联系供应商
Other supplier products
 |
Air Filter Flow Rate Resistance Test Equipment | Whats/App: +86 156 1874 6768 Web: standard-groups.com Standards You can operate this tester in compliance with the following standards: (1) ISO... |
 |
