Combined Salt Spray Test Chamber
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
This chamber is widely used in industries and laboratories to assess corrosion resistance and durability of materials under accelerated environmental conditions:
Photovoltaic Modules and Backplates: Salt spray corrosion resistance testing.
Metal Plated Parts: Evaluation of corrosion resistance for zinc, nickel, chromium plating, etc.
Coating Materials: Research on organic coatings and powder coatings corrosion resistance.
Anodized Aluminum and Protective Films: Durability and longevity testing.
Anti-Rust Oils and Surface Treatments: Performance verification of corrosion protection.
Marine, Automotive, and Transportation Components: Corrosion resistance assessment.
Electronics, Electrical, and Outdoor Machinery: Salt spray aging testing.
Accelerated Aging Experiments and Quality Control: Laboratory evaluation for product development and QC.
Standards
The chamber is designed to comply with international and domestic corrosion testing standards, including but not limited to:
GB/T 2423.17-2008 – Environmental Testing for Electric and Electronic Products, Salt Spray Test Method
GB/T 10125-2012 – Salt Spray Test
IEC 61701-2011 – Salt Mist Corrosion Testing of Photovoltaic Modules
ISO 9227-2017 – Corrosion Tests in Artificially Created Salt Atmospheres
Parameters
| Item | Technical Parameter |
|---|---|
| Chamber Volume | Approx. 3.8 m³ |
| Internal Dimensions | 1200 × 1600 × 2500 mm (W×H×D), excluding sloped top height |
| External Dimensions | 2000 × 2400 × 2800 mm (W×H×D), excluding control cabinet |
| Control Cabinet Size | 600 × 1500 × 1000 mm (W×H×D) |
| Solution Tank Size | 600 × 600 × 1000 mm (L×W×H) |
| Weight | Approx. 1000 kg |
| Base Load Capacity | Approx. 200 kg |
| Noise Level | ≤70 dB (1 m in front, 1.2 m above ground) |
| Max Power | 26 kW |
| Max Current | 60 A |
| Power Supply | AC 380V, Three-phase Four-wire + Protective Ground ±10%, 50±0.5 Hz |
| Temperature Range | RT – 55℃ |
| Pressure Tank Temperature | RT – 63℃ |
| Relative Humidity | 30 – 95% RH |
| Relative Humidity Deviation | +2%, -3% |
| Temperature Resolution | 0.1℃ |
| Temperature Deviation | ±1℃ |
| Temperature Uniformity | ≤2℃ |
| Temperature Fluctuation | ≤±1℃ |
| Salt Spray Deviation | ≤±1% |
| Spray Rate | 1–2 ml/80 cm³ |
| pH Value | 6.5 – 7.2 |
| Spray/Static Time | 1 min – 9999 h, programmable cycles |
| Heating Rate | Chamber RT→50℃ ≤60 min; Tank RT→63℃ ≤60 min |
| Sample Capacity | At least 2 modules (2000×1000×38 mm) |
