BBA-Grade Desktop/Vertical Solar Simulator for Photovoltaic Module Testing
Get a quote：
Web: qinsun-lab.com
Email：info@qinsun-lab。com
TheBBA-Grade Desktop/Vertical Solar Simulator for Photovoltaic Module Testingis a high-precision, laboratory-grade device designed to simulate solar irradiation for indoor photovoltaic testing and controlled sunlight experiments. You can use this simulator to replicate solar intensity, spectrum, and irradiance on a defined plane, enabling accurate evaluation of photovoltaic module performance, solar thermal responses, photochemical reactions, and plant growth studies. Its compact desktop or vertical configuration ensures convenient operation while maintaining high accuracy, stability, and versatility across diverse indoor applications.
Standards
(1) IEC 60904-9 – Photovoltaic Devices: Requirements for Solar Simulators
(2) ASTM E927 – Laboratory Simulation of Solar Radiation
(3) IEC 60904-3 – Measurement of Photovoltaic Current-Voltage Characteristics
(4) ISO 9060 – Solar Irradiance Measurement Standards
(5) ASTM G173 – Reference Solar Spectra for Testing
(6) JIS C 8912 – Performance Guidelines for Solar Simulators
Technical Parameters
| Performance Item | Technical Specification |
|---|---|
| Simulator Type | Desktop / Vertical BBA-Grade |
| Light Source Type | High-brightness LEDs with multi-channel spectral control |
| Light Source Lifespan | ≥20,000 hours |
| Illuminated Area | Adjustable plane, typical: 0.3 × 0.3 m up to 1 × 1 m |
| Maximum Irradiance | Up to 1000 W/m², user-adjustable |
| Minimum Irradiance | 100 W/m² |
| Spectral Range | 400–1100 nm (adjustable for BBA grade) |
| Spectral Matching | Class BBA standard, multi-channel LED control |
| Light Uniformity | ±2% across effective test plane |
| Control Modes | Manual, Programmed, Timed Flash Modes |
| Equipment Dimensions | Desktop: 0.8 × 0.5 × 0.7 m; Vertical: 1.2 × 0.6 × 1.8 m |
| Operating Voltage | 220 V ±10% AC, 50/60 Hz |
| Cooling System | Integrated air cooling with thermal protection |
