TDM Cutting Resistance Tester

Get a quote:

Web: qinsun-lab.com

Email:serving@qinsun-lab。com

The TDM straight blade travels once across the test material and is only used once. TDM Test rates materials on a scale of A - F and uses an oscillating blade that measures the force necessary to cut through high-cut materials. Materials that test beyond Level 3 or produce a false Coupe Test reading will receive an "X", and the TDM Test is introduced where a letter rating A - F is determined (Example 4X43FP). If the TDM Test isn't required, an "X" is used to state that there's no rating (Example 4243XP).

Application:

This machine is used for TDM grading test (cutting force N) of gloves, protective clothing fabrics and other fabrics, composite materials, rubber and other materials for cutting resistance.

Standards:

ISO 13997, BS EN 1082-2:5.4, EN 388, GB 24541-2022:6.3, ASTM F2992/F2992M-15, ANSI/ISEA 105-2016:5.1.1

Technical Specifications:

Vertical Cutting Force Load 0~100N
Horizontal Cutting Force 25N
Total Vertical Stroke Of Sample Rack 35mm
Effective Vertical Stroke Of Sample Rack 10mm
Cutting Speed 150mm/min@±10%
Cutting Stroke 200mm
Test Loading Stand Lever Ratio 2:01
Cutting Distance Reading Accuracy 0.01mm, graduation value 0.001mm
Annular Combination Weight Specification 2kg-1mg (ring weight + sheet weight) 1 set
Power 1phase, AC 220V 50Hz 500W
Dimension (W×D×H) 45×45×44cm
Weight Approx 20kg
