50th Percentile Male Side Impact Dummy
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The 50th Percentile Male Side Impact Dummy is primarily used for:
(1) Vehicle side impact occupant protection testing;
(2) Evaluation of B-pillar, door trim, and sill beam crashworthiness;
(3) Verification of side airbags and curtain airbag restraint systems;
(4) Safety development and regulatory certification for new or updated vehicle models;
(5) Occupant injury assessment and crash safety research;
(6) High-repetition crash data collection for research institutions and testing labs;
(7) International and regional NCAP (Euro NCAP, C-NCAP, U.S. NCAP, etc.) side impact tests.
Standards
(1) GB/T 11551 – Protection of occupants in frontal and side collisions
(2) GB 14166 – Motor vehicle seat belts and restraint systems
(3) FMVSS 214 – Side impact protection
(4) UNECE R95 – Lateral collision protection
(5) UNECE R135 – Pole side impact
(6) SAE J1727 – Side impact dummy performance specification
(7) ISO 15830 – Road vehicles – Side impact dummy – Calibration
(8) ISO/TR 9790 – Road vehicles – Side impact dummy – Evaluation method
(9) Euro NCAP – Side impact test protocol
Parameters
Dimensional Data
| No. | Item | Dimension (mm) |
|---|---|---|
| L1 | Sitting height | 869 ±30 |
| L2 | Hip joint pivot height | 79 ±15 |
| L3 | Hip pivot to back distance | 175 ±28 |
| L4 | Thigh gap | 176 ±29 |
| L5 | Foot to knee height | 588 ±30 |
| L6 | Knee to back distance | 670 ±30 |
| L7 | Rear head to back distance | 147 ±22 |
| L8 | Upper rib thorax depth | 208 ±30 |
| L9 | Lower rib/abdomen thorax depth | 228 ±30 |
| L10 | Arm length | 330 ±30 |
| L11 | Arm breadth | 468 ±30 |
| L12 | Waist breadth | 324 ±30 |
