Vacuum Cleaner Full-Unit Charge-Discharge Life Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
TheVacuum Cleaner Full-Unit Charge-Discharge Life Testeris designed for long-term evaluation of vacuum cleaner battery performance and overall unit durability. You use this equipment to simulate extended charge and discharge cycles, monitoring voltage, current, power, suction force, and temperature variations. PLC-controlled automation enables precise recording of cycle counts and durations, while the system automatically pauses upon fault detection or completion. This tester ensures accurate life-cycle analysis, enhances operational efficiency, and allows unattended, fully automated testing of complete vacuum cleaner units.
Standards
IEC 60312: Household and Similar Electrical Appliances – Vacuum Cleaners – Methods for Measuring Performance
GB/T 20291.1-2014: Household and Similar Electrical Appliances – Vacuum Cleaners – Part 1: Methods for Measuring Performance
IEC 62885-2:2020: Surface Cleaning Appliances – Part 2: Dry Vacuum Cleaners for Household or Similar Use – Methods for Measuring Performance
IEC 62133-2:2017: Secondary Cells and Batteries Containing Alkaline or Other Non-Acid Electrolytes – Safety Requirements for Portable Sealed Secondary Cells, and for Batteries Made from Them
GB/T 31467.3-2015: Lithium-ion Battery Pack and Systems for Electric Vehicles – Test Methods for Performance
Technical Parameters
| Item | Specification |
|---|---|
| Test Stations | 12 stations, 6+6 back-to-back configuration |
| Control Interface | 7-inch color touch screen + Mitsubishi PLC (Japan) |
| PLC | Mitsubishi (Japan), with power failure data memory function |
| Voltage & Current | Voltage: AC 0–300V (adjustable), DC 0–36V (adjustable); Current detection: 0–30A |
| Time Setting Range | 1–9999999 hours/minutes/seconds |
| Detection Function | Whole machine service life testing |
| Equipment Power Supply | 220V, 3.5KW |
| Equipment Dimensions | 1650×1200×1650 mm |
