50th Percentile FAA Crash Test Dummy
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The 50th Percentile FAA Crash Test Dummy is a professional, anthropomorphic test device designed for emergency landing and dynamic aircraft seat testing. You can use this dummy to assess aircraft seat restraints and occupant injury under simulated emergency conditions. Developed from standard 50th percentile male anthropometric data, it retains Hybrid III biomechanical response characteristics while adapting the pelvis, thigh, and torso structures to meet FAA 14 CFR requirements.
Standards
This dummy complies with multiple international standards, including:
(1) FAA 14 CFR Parts 23 / 25 – Airworthiness Standards for Transport and Normal Category Aircraft
(2) ISO 9790 / ISO/TR 9790 – Road Vehicles: Side Impact Dummy Evaluation Methods
(3) FMVSS 208 – Occupant Crash Protection
(4) FMVSS 213 – Child Restraint Systems (modified for aircraft seats)
(5) ECE R21 – Uniform Regulations for Seat and Restraint Certification
Parameters
Key Dimensions
| No. | Name | Dimension (mm) |
|---|---|---|
| A | Seated Height | 909.3 ±8 |
| B | Shoulder Pivot Height | 533.4 ±8 |
| C | H-Point Height (Ref.) | 121.9 ±8 |
| D | H-Point to Seatback (Ref.) | 94.0 ±8 |
| E | Shoulder Pivot to Back Plane | 88.9 ±5.1 |
| F | Thigh Thickness | 147.3 ±7.6 |
| G | Elbow to Wrist Pivot | 297.2 ±7.6 |
| H | Head Back to Back Plane | 43.2 ±2.5 |
| I | Shoulder to Elbow | 337.8 ±7.6 |
| J | Elbow to Seat Plane | 226.1 ±10 |
| K | Knee Front to Back Plane | 591.8 ±12.7 |
| L | Foot to Seat Plane | 442.0 ±12.7 |
| M | Knee Pivot to Floor | 492.8 ±7.6 |
| N | Hip to Popliteal Distance | 464.8 ±12.7 |
| O | Chest Thickness (unclothed) | 221.0 ±7.6 |
| P | Foot Length | 259.1 ±7.6 |
| V | Shoulder Width | 429.3 ±7.6 |
| W | Hip Width | 363.2 ±7.6 |
| R | Foot Width | 99.1 ±7.6 |
| Y | Chest Circumference | 1028 ±15 |
| Z | Waist Circumference | 876 ±15 |
| AA | Chest Circumference Reference | 431.8 ±2.5 |
| BB | Waist Circumference Reference | 228.6 ±2.5 |
