Walk in High Temperature Environmental Test Chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
The High-Temperature Aging Chamber is a critical testing apparatus designed to simulate high-temperature and harsh environmental conditions for high-performance electronic products such as complete computers, monitors, terminals, servers, cameras, automotive electronics, PCBs, power supplies, motherboards, monitors, electrical appliances, and switch-mode chargers. It serves as an essential experimental device for enhancing product stability and reliability, and is a vital production process for improving product quality and competitiveness.
Standards
GB50052-95 Code for Design of Power Supply and Distribution
GB50054-95 Code for Design of Low-Voltage Distribution
GB50169-92 Code for Construction and Acceptance of Grounding Installations in Electrical Installation Engineering
Features
1. Control system integration with aging function design. The control cabinet features functional design, enabling operation of aging duration, temperature, and various switches from a single unit. The cabinet panel boasts an aesthetically pleasing design and intuitive operation.
2. Fully automated aging process with partial anomaly self-handling capabilities, streamlining operations for simplicity and automation.
3. Multiple safety protections ensure reliable operation.
4. Electric heating prevents dry burning. Automatic power shutdown occurs during fan failure or excessive duct temperatures, accompanied by audible alarms.
5. Interlocked heating and fan operation: Heaters cannot activate independently if fans fail to start.
6. High-temperature resistant wiring (non-combustible at 300°C) connects all heating elements.
7. Equipped with a 40W high-temperature-resistant explosion-proof indoor light fixture, extending bulb lifespan and preventing bulb explosions.
8. Chamber body constructed with flame-retardant insulation material, offering excellent thermal performance and high safety margins.
9. Over-temperature audible/visual alarm function: During aging processes, the chamber automatically cuts power and triggers an alarm upon detecting over-temperature or overload conditions.
Parameters
| Item | Specifications |
|---|---|
| Dimensions | Room size specified by the customer according to on-site conditions |
| Insulation Material | Rock wool or polyurethane (choose one); thickness: 5.0 cm, 7.5 cm, 10 cm, or customer-specified |
| Temperature Range | RT ~ +45°C / ~70°C / ~+85°C |
| Temperature Fluctuation | ±1°C |
| Temperature Deviation | ±2°C / ±3°C / ±5°C, etc. (measured under no-load conditions) |
| Operation Mode | Temperature adjustable, constant temperature and fixed value operation (PLC program control or fixed value control) |
| Heating Power | Determined by the size of the aging chamber |
| Installation Power | 380V, 50 Hz; if using 220V power, a minimum current supply of 120A is required |
Accessories
Microcomputer PID temperature controller with digital display.
PT-100 platinum resistance sensors.
Stainless steel or galvanized ducting and high-performance axial fans.
Control panel with safety switches and indicators.
Explosion-proof internal lighting.
Optional exhaust system for temperature stabilization.
