Automatic Transmission Fluid Anti-Shudder Friction Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The Passenger Vehicle Automatic Transmission Fluid Anti-Shudder Friction Tester is a specialized friction testing system designed to evaluate the friction characteristics and anti-shudder durability of automatic transmission fluids (ATF) under controlled pressure, speed, and temperature conditions.
You can use this tester to accurately simulate the real operating conditions of wet friction pairs in automatic transmissions, enabling quantitative analysis of friction behavior during running-in, low-speed operation, and long-term durability. It provides reliable technical support for lubricant development, quality control, and compliance verification.
Application
You can apply this tester to a wide range of automotive transmission fluids, friction materials, and research scenarios, including:
(1) Passenger vehicle automatic transmission fluids (ATF)
(2) Dual clutch transmission fluids (DCTF)
(3) Continuously variable transmission fluids (CVTF)
(4) Lubricants for wet clutch systems
(5) Automatic transmission friction plates and steel plates
(6) Anti-shudder performance development of new lubricant formulations
(7) Durability evaluation and performance degradation analysis of in-service fluids
Typical users include petrochemical companies, lubricant manufacturers, vehicle and transmission OEMs, third-party testing laboratories, universities, and research institutes.
Standards
The tester is designed to meet and support the following domestic and international standards and test methods:
(1) GB/T 11118 — Tribological Performance Test Methods for Lubricants
(2) GB/T 3142 — General Test Methods for Lubricant Viscosity and Performance
(3) JASO M348 — Friction Characteristics Test Method for Automatic Transmission Fluids
(4) SAE No.2 — Friction Test Method for Automatic Transmission Fluids
Note: Differences in speed profiles, loading modes, temperature programs, and data processing requirements among standards can be accommodated through software parameter configuration.
Parameters
| Category | Parameter | Technical Specification | Remarks |
|---|---|---|---|
| Load system | Axial load range | 200 N – 10,000 N | Servo-hydraulic loading |
| Load indication relative error | ±0.5% | ||
| Long-term load holding error | ±0.05 MPa | ||
| Stroke | Axial loading stroke | 150 mm | |
| Friction measurement | Maximum friction torque | 320 N·m | |
| Friction torque relative error | ±2% | ||
| Drive system | Sliding speed range | 0.01 – 1.5 m/s | Continuously adjustable |
| Speed control accuracy | ±0.01 m/s | ||
| Drive motor | 380 V / 11 kW | AC servo motor | |
| Temperature control | Temperature range | –30 °C to 200 °C | Indirect heating & cooling |
| Temperature control accuracy | ±2 °C | ||
| Heating power | 220 V / 300 W | ||
| Cooling power | 220 V / 2.37 kW | ||
| System power | Total power | 16.5 kW | Including load, drive, temperature |
| Control & monitoring | Time setting range | 1 s – 9999 min | |
| Real-time monitored parameters | Load, friction force, speed, temperature, time |
