ISO / JIS crocking fastness tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The Rubbing Color Fastness Tester is suitable for rubbing color fastness testing of materials in the following fields:
Textiles:
Such as dyed textiles, fabrics, and woven materials, for evaluating color fastness after rubbing.
Flocked Fabrics:
For friction strength testing of various flocked fabrics.
Artificial Leather:
Such as synthetic leather and artificial leather, for rubbing discoloration tests.
Paperboard and Packaging Materials:
Including cartons, paperboard, and packaging bags, for evaluation of rubbing durability.
Printing Inks:
For assessing the rubbing resistance of inks on printed surfaces.
Coatings:
For evaluating rubbing and abrasion resistance of various coating materials.
Traffic Signs and Advertising Materials:
Such as outdoor billboards, subway signs, and bus signs, for friction testing.
Others:
Including plastic products and electronic product housings, for rubbing durability testing.
Standards
JIS L0849 — Test methods for color fastness of textiles — Rubbing color fastness test method
JIS L1084 — Color fastness tests of textiles — Rubbing test method
JIS P8136 — Test method for rubbing durability of printed matter
Accessories
| Accessory | Quantity | Description |
|---|---|---|
| Flat test table | 1 | For general sample testing |
| Transparent resin safety cover | 1 | Enhances operational safety |
| 1.5 R rubbing head | 1 | Curvature radius 1.5 mm |
| Sharp-angle rubbing head | 1 | For flocked product testing |
| Load weights (300 g, 500 g, 800 g) | 1 set | Provides different load options |
| Thick fabric sample fixing device | 1 | Maximum thickness 8 mm |
| Flat rubbing head (20 × 20 mm) | 1 | For ink and coating tests |
Test Principle
The Rubbing Color Fastness Tester evaluates material rubbing performance by simulating actual friction conditions using a specified load, defined rubbing head shape, and standardized reciprocating distance.
The rubbing head repeatedly rubs the test material to assess color transfer, rubbing marks, and wear degree caused by friction, thereby determining the rubbing color fastness of the material.
Operating Instructions
Sample Preparation:
Select an appropriate rubbing head and load weight according to the material type.
Equipment Setup:
Set the curvature radius of the test table and the load value in accordance with the test standard to ensure accurate test conditions.
Start Test:
Press the start button; the rubbing head automatically performs the specified reciprocating motion and records test data.
Test Completion:
After the test, evaluate the sample according to color difference assessment standards and perform data analysis.
Safety Precautions:
Ensure the safety cover is properly installed during operation to prevent accidental contact with moving components.
