ASTM D4060 Abrasion Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The Taber abrasion tester has a wide range of applications, covering multiple industries and fields. Its main application areas include:
1. Coatings Industry: Used to test the abrasion resistance of coatings to evaluate their durability and service life in practical use.
2. Plastics Industry: Used to test the abrasion resistance of plastic products to evaluate their service life under mechanical friction, chemical corrosion, and other environments.
3. Rubber Industry: Used to test the abrasion resistance of rubber products to evaluate their service life and performance under friction, extrusion, and other environments.
4. Paper Industry: Used to test the abrasion resistance of paper to evaluate its durability and quality during printing, writing, and other processes.
5. Textile Industry: Used to test the abrasion resistance of textiles to evaluate their durability and quality during wearing, washing, and other processes.
6. Flooring Industry: Used to test the abrasion resistance of flooring materials to evaluate their service life and performance under foot traffic, friction, and other environments.
In addition, the Taber abrasion tester is widely used in the automotive, electronics, and construction industries, providing strong support for material quality control and performance evaluation.
Standards
ISO Standards: ISO 9352. ISO 5470. ISO 7784
ASTM Standards: ASTM D1044. ASTM D3884. ASTM D4060
Chinese Standards: GB/T 5137.1. QB/T 2726
German Standard: DIN 53109
ASTM D3884. ASTM D1175. ASTM D1044. ASTM D4060. ASTM D4685.
TAPPI T476. ISO 9352. ISO 5470-1.
JIS K7204. JIS A1453. JIS K6902. JIS L1096. JIS K6964. DIN 52347. DIN 53109.
DIN 53754. DIN 53799. SATRA TM163
Parameters
| Parameter | Specification |
|---|---|
| Rotational Speed | Adjustable: 30–75 RPM (digital control) |
| Sample Diameter | 100 mm |
| Test Platform Diameter | 113 mm |
| Cycle Range | 1–999.999 revolutions (presettable) |
| Air Pressure | 250g (standard) |
| Weight Options | 250g, 500g, 750g, 1000g (included); 125g (optional) |
| Wheel Pressure Range | 125g, 250g, 500g, 750g, 1000g, 1250g |
| Vacuum Arm Adjustment | Height-adjustable |
| Power Supply | 220V, 50Hz |
| Dimensions | 220 (W) × 380 (D) × 300 (H) mm |
| Net Weight |
20 kg |
Accessoriess
Standard accessories:Grinding wheel system,Worktable.Control system,Counter,Load unit.
Test Procedures
The typical test procedure for the Taber abrasion tester includes:
1. Preparing the accessories and test sample.
2. Mounting and securing the prepared sample on the test platform.
3. Mounting the friction wheel onto the clamp and applying the balance weights to both sides.
4. Adjusting the vacuum pump's suction height and removing debris from the sample.
5. Mounting the sample at the other station of the instrument in the same manner.
6. Turning on the instrument and setting the bearing drive count on the timer.
7. Starting the instrument; the friction wheel will circulate and rub the sample at a set speed.
8. The test will automatically stop after reaching the set value. Remove the friction wheel and weights, loosen the clamp, and remove the sample.
9. The test is complete. Turn off the instrument, remove the sample for analysis and comparison to evaluate the material's abrasion resistance.
