Safety Helmet Lateral Rigidity Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Safety Helmet Lateral Rigidity Tester is a precision instrument designed to evaluate the lateral deformation resistance of helmets under controlled loading. It measures force-displacement behavior with high accuracy, ensuring compliance with national and international helmet safety standards. The tester accommodates various helmet sizes and types, providing repeatable and reliable testing for both production quality control and R&D applications.
Application
This tester is suitable for evaluating lateral rigidity in various helmet testing scenarios, including:
(1) Industrial safety helmets used in construction, manufacturing, and mining
(2) Cycling helmets for road and mountain biking
(3) Sports helmets for skating, skiing, and snowboarding
(4) Motorcycle and E-bike helmets for rider safety certification
(5) Quality control and R&D of helmet designs with different shell materials or thicknesses
Standards
The tester complies with the following standards:
(1) GB 2812 – Safety Helmets (China National Standard)
(2) ISO 6220-2 – Industrial Safety Helmets: Lateral Deformation
(3) CE Certification (Conformité Européenne)
(4) ISO 17025 – General requirements for testing and calibration laboratories
Features
High-Precision Lateral Testing: 0–1,000N load capacity with 0.1mm displacement resolution.
Accurate Force Control: ±1% force accuracy and adjustable test rate of 100N/min.
User-Friendly Operation: 7” touchscreen HMI with preloaded GB 2812 test sequences and auto-hold functions.
Quick-Swap Helmet Clamp: Enables rapid replacement of helmets for high-throughput testing.
Data Integrity: Built-in data logger exports force-displacement curves in PDF/CSV formats for audit trails.
Durable Construction: Aircraft-grade aluminum frame and stainless steel sensors resist deformation and corrosion.
Dynamic Force Feedback: Real-time monitoring of peak loads via 0.1N resolution load cell.
Self-Calibrating System: Auto-tare and linearity checks ensure measurement reliability.
Rust-Resistant Frame: 304 stainless steel with epoxy coating for laboratory durability.
Parameters
| Parameter | Specification |
|---|---|
| Force Capacity | 0–1,000N (100 kgf capacity) |
| Force Accuracy | ±1% of reading |
| Displacement Resolution | 0.1mm (ISO 17025 traceable) |
| Test Rate | 100N/min ±10N/min (configurable) |
| Max Travel Distance | 600mm (23.6”) |
| Power Supply | 220V AC, 50/60Hz (single-phase) |
| Dimensions | 700mm (W) × 500mm (D) × 1,300mm (H) |
| Weight | 95 kg (net) |
