Carton drop tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Carton Drop Tester is designed to simulate the impact experienced by packaging during transportation, handling, and loading/unloading. It evaluates the impact strength of packages, the durability of materials, and the rationality of packaging design by performing controlled free-fall drops.
Applications
This tester is widely used in the packaging, logistics, electronics, food, pharmaceutical, and e-commerce industries. It is suitable for manufacturers of corrugated cartons, boxes, and transport packaging to ensure product protection and optimize packaging design.
Standards
The Carton Drop Tester meets the following international and national standards:
ISO 2248 – Packaging — Transport packages — Vertical impact test by dropping
GB/T 4857-5 – Packaging — Transport packages — Vertical impact test by dropping
ASTM D5276 – Standard test method for drop test of loaded containers by free fall
ISTA 1A, 2A, 3A – International Safe Transit Association protocols
ASTM 4619 – Standard test methods for packages
IEC 60068-2-31 – Environmental testing — Drop test
JIS Z0202 – Japanese Industrial Standard for package drop testing
EN 438-2.21 – High-pressure decorative laminates — Determination of impact resistance
Advantages
Accurate and repeatable testing with consistent results
Simulates real-world handling and shipping conditions
Identifies weak points in packaging design
Ensures adequate product protection
Supports compliance with international standards
Provides data for optimizing packaging strength and cost
Features
Adjustable drop height from 300 mm to 1500 mm
Free, reliable, and precise release mechanism
Capable of surface, edge, and corner drop tests
Rigid impact surface to ensure consistent test conditions
Motorized or pneumatic lifting mechanism
Digital controls and touch-screen interfaces (optional)
Safety features to protect operators and equipment
Sturdy frame supporting packages up to 70 kg
Technical Parameters
| Parameter | Specification |
|---|---|
| Drop height | 300–1500 mm (adjustable) |
| Maximum sample weight | 70 kg |
| Maximum sample size | 800 × 800 × 800 mm |
| Impact panel size | 1700 × 1200 × 14 mm |
| Motor power | 1.85 kW |
| Overall dimensions (L × W × H) | 1700 × 1200 × 2350 mm |
| Net weight | ~600 kg |
| Power supply | AC 380 V, 50 Hz |
| Control | Motorized and pneumatic lifting, wired remote control |
| Drop test modes | Surface, edge, corner |
