Abrasion and scratch protective material tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
You can use this tester for the following applications and test materials:
Scratch resistance evaluation of plastic molded products
Scratch property testing of film materials
Surface scratch performance assessment of coatings, paints, and sprayed materials
Scratch resistance testing of automotive interior and exterior components
Scratch durability testing of optical materials, packaging materials, and electronic housings
Scratch damage analysis during material research, development, and quality control
Standards
The tester complies with the following international standards:
ISO 19252 — Plastics — Determination of scratch resistance of plastics and coated plastics by progressive load test
ASTM D7027-05 — Standard Test Method for Instrumented Indentation Test for Plastics (Scratch Resistance Test)
Parameters
| Parameter | KK-01 | KK-02 | KK-03 |
|---|---|---|---|
| Dimensions (mm) | W965 × D530 × H690 | W545 × D455 × H680 | W545 × D455 × H680 |
| Weight | 150 kg | 65 kg | 150 kg |
| Power supply | AC 100 V | AC 100 V | AC 100 V |
| Maximum power consumption | 60 W | 60 W | 60 W |
| Operating environment | 10–40 ℃, 30–70 %RH, non-condensing | Same as left | Same as left |
| Test method | Progressive load method | Progressive load method | Progressive load method |
| Scratch direction | Left → Right | Left → Right | Left → Right |
| Vertical load range | 1–200 N | 1–50 N | 0.1–5 N |
| Horizontal load | Max. 200 N | 50 N | 5 N |
| Scratch distance | Max. 400 mm | Max. 400 mm | Max. 400 mm |
| Scratch speed | 1–400 mm/s | 1–200 mm/s | 1–200 mm/s |
| Scratch depth detection | Laser displacement sensor | Laser displacement sensor | Laser displacement sensor |
| Sample size | 200 × 420 mm, thickness ≤ 5 mm | Same as left | Same as left |
Accessories
(1) Standard scratch stylus Φ1 mm (for ISO/ASTM standard testing)
(2) Optional scratch styli (gloss scratch, scale scratch, cutting scratch, etc.)
(3) Safety cover (optional, for operator protection)
(4) USB connection cable
(5) Software and user manual
Test Procedures
Fix the sample securely on the test stage and ensure it is flat and stable.
Select the test mode and set vertical load, scratch speed, and scratch distance via the touchscreen.
Use the teaching function to calibrate the load area and scratch starting position if required.
Start the test. The stylus applies vertical load and moves horizontally while data are recorded in real time.
After the test, save the data and proceed with result analysis.
