Cloud-based dust ignition temperature logger
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
1. Chemical Industry: Determine the Material Effects (MI) of chemical dusts such as organic synthesis intermediates and plastic powders to guide explosion-proof safety design in production/storage processes;
2. Food Processing Industry: Test the MI of food dusts such as flour and sucrose powder to optimize safety measures for dust control in workshops;
3. Mining/Materials Industry: Assess the ignition risk of dusts such as coal dust, aluminum dust, and wood dust to assist in the configuration of explosion-proof facilities in mines and material processing plants;
4. Light Industry: Test the MI of tobacco powder and plant fiber powder to support workshop safety management and risk classification;
5. Safety Testing Institutions: Conduct compliance testing and certification for dust explosion risks based on standards such as ASTM and IEC.
Standards
ASTM E2019:Standard Test Method for Minimum Ignition Temperature of Dust Layers
IEC 61241-2-3:Electrical Apparatus for Use in Explosive Dust Atmospheres - Part 2-3: Test Methods - Determination of Minimum Ignition Temperature of Dust Layers
ISO/IEC 80079-20-2:Explosive Atmospheres - Part 20-2: Equipment Protection Levels (EPL) - Classification of Equipment for Dust Atmospheres
GB/T 16428:Test Method for Explosion Limits of Dust Clouds
Technical Parameters
|
Operating Environment |
(5～45)℃, <85%RH |
|
General Purpose Mode |
1 mJ,3 mJ,10 mJ |
|
Spark Energy |
30 mJ,100 mJ,300 mJ,1000 mJ,3000mJ |
|
Custom Mode |
(1～3000)mJ, settable, step 1mJ |
|
Spark Energy |
(0～15)kV |
|
Charging Voltage |
No load, 1mH inductive load |
|
Discharge Load |
1.2L Hartmann Tube |
|
Experiment Vessel |
Diameter 2mm Tungsten Electrode |
|
Electrodes |
(2～10)mm, Adjustable |
|
Electrode Spacing |
High Voltage relay triggered,... Moving electrode trigger |
|
Electrode Trigger Mode |
20ms～180ms, adjustable |
|
Ignition Delay Time |
0.4MPa～0.7MPa, adjustable |
|
Powder Spray Pressure |
USB*2 |
|
Interfaces |
90～260VAC/47～63Hz |
|
Power |
300W |
Accessoriess
1. Hartmann tube testing device (core chamber for forming a uniform dust cloud)
2. Compressed air delivery assembly (including pressure regulation module for dust dispersion)
3. Spark ignition energy regulation assembly (provides different spark energies to suit testing needs)
4. Dust sample quantitative feeding device (precisely controls the quality of test dust)
5. Hartmann tube seal (ensures the sealing performance of the test chamber)
6. Calibration standard dust sample (calibration component for reference standards)
7. Data acquisition and analysis module (synchronously records ignition test data)
