Self accelerating decomposition temperature test system
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
The Autocatalytic Decomposition Temperature Tester with Thermal Insulation is a core device for assessing the thermal hazards of chemicals, used to determine a substance's heat release rate as it changes with temperature. The measured heat release parameters, combined with thermal loss data for the relevant package, are used to determine the substance's autocatalytic decomposition temperature within its container. This method is applicable to all types of containers, including intermediate bulk containers and tanks.
Parameters
| Item | Specifications |
| Operating Environment | (-5 ~ 45)°C, <95% RH |
| Chamber Temperature Control Range | -20°C ~ 220°C |
| Temperature Control Accuracy | ±1°C |
| Sample Temperature Measurement Range | (-50 ~ 500)°C |
| Sample Temperature Measurement Resolution | 0.1°C |
| Sample Temperature Measurement Accuracy | ±（2.5或0.0075×|t|）℃ |
| Dewar Flask Capacity | 1 L |
| Constant Power Adjustment Range | 0.1W ~ 2W |
| Constant Power Accuracy | ≤0.015W |
| Temperature Rise Rate Range | 0 ~ 2°C |
| Refrigerant Circulation Rate | ≥3 L/min |
| Dewar Flask Material | Glass inner liner |
| Instrument Dimensions (L×W×H) | 930mm × 545mm × 875mm |
Accessories
Glass Dewar Flask (1L): High-insulation vessel for adiabatic containment.
High-Precision Temperature Probes: Specialized sensors for sample and environment monitoring.
Coolant Circulation Kit: Pumps and hoses for the active cooling system.
Pressure Relief Door Assembly: Rear-mounted safety mechanism.
Software Suite: Pre-installed Windows CE testing and reporting software.
