The Airflow Method Fabric Drying Rate Tester is an automated testing instrument designed to measure the drying rate of textiles in accordance with the requirements of the American Association of Textile Chemists and Colorists (AATCC) Test Method 200.
Standards
AATCC 200-2017: Drying Rate of Textiles at their Absorbent Capacity: Airflow Method.
GB/T 43822-2024: Textiles — Determination of drying rate at maximum water absorption capacity.
ISO 17617: (Related Reference) Textiles — Determination of moisture drying rate.
Features
1. Incorporates high-precision wind speed sensors, infrared temperature sensors, moisture measurement sensors, high-precision wind speed control devices, and alternating drip-sensing and infrared measurement mechanisms.
2. Combined with software, it automatically completes fabric maximum water absorption measurement, drying time and drying rate testing, along with a series of data analyses. This significantly enhances work efficiency and measurement accuracy while reducing errors and mistakes caused by manual operation.
3. The drying rate tester software transmits data to the host via USB port. Data is displayed and saved in graphical and chart formats for convenient user analysis and printing.
4. Wide adjustable ranges for wind speed (0.2–4.5 m/sec) and drip volume (0.05–4.5 ml).
5. The airflow method tester not only meets the AATCC 200 testing standard but also serves as a valuable tool for fabric designers.
Parameters
| Item | Specifications |
|---|---|
| Air Chamber Specification | 165mm×165mm×27.5mm±1mm |
| Air Chamber Opening Diameter | 130.0mm±1mm |
| Air Velocity | 0.2 m/s – 4.5 m/s ± 0.1 m/s |
| Infrared Temperature Sensor | 15–50°C±0.1°C |
| Water Dropping Accuracy | 0.05ml - 1.00ml ± 0.003ml; 1.00ml - 4.50ml ± 0.010ml |
| Data Transmission | USB data transmission |
| Test Interface | Curves and charts displayed simultaneously |
| Test Report | Automatically saved, easy to print |
| Power Supply | AC 230V, 50Hz/60Hz |
| Overall Dimensions (L×W×H) | 500×500×560 mm |
| Weight | Approximately 40 kg |
| Optional Accessories | 1. Drying Rate Tester Main Unit + Software2. Drying Rate Tester Software3. Dedicated Computer4. Sample Press Rod5. USB Data Cable |
