Surface adhesion testing equipment factory price
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
JIS L 1066 (Testing Methods for Woven Fabrics)
JIS L 1085 (Testing Methods for Nonwoven Fabrics)
JIS L 1086 (Testing Methods for Textile Products)
JIS P 8139 (Determination of Adhesion and Peel Strength of Paper and Board)
Parameters
| Parameter | Specification |
|---|---|
| Measurement range | Load cells available: 0–100 gf, 0–2000 gf |
| Traveling speed | Clamp traveling speed: 50–500 mm/min |
| Measurement speed | Opposing clamp speed: 100–1000 mm/min |
| Travel distance | Stroke per clamp: 150 mm |
| Specimen size | Maximum: 200 mm × 75 mm |
| Output signal | 0 to ±5 V (within ±0.05% FS) |
| Frequency response | 2 kHz / −3 dB |
| Operating environment | Temperature: 0–50 °C |
| Relative humidity: ≤85%, non-condensing | |
| Power supply | AC 100 V, 50/60 Hz |
| Dimensions | W 630 mm × D 310 mm × H 350 mm |
Features
Wide measurement capability from very low to relatively high adhesion forces
Supports multiple test modes, including T-peel, 180° peel, tensile, tear, and surface adhesion tests
Desktop-type design suitable for laboratory and on-site testing
Portable structure allows convenient measurements in different locations
Simple zero balance and calibration procedures enable quick and intuitive operation
Stable opposing-motion mechanism ensures consistent and repeatable test results
Accessories
(1) Load sensor
(2) Relay cable, 1 m
(3) Power cable with E-type plug, 2 m
(4) Acrylic protective cover
(5) Tool set
(6) Parts storage box
(7) Operating manual
Optional: Tribosoft analysis software
Test Procedures
Prepare the specimen according to the required test method and standard.
Secure each end of the specimen firmly in the opposing clamps.
Select the appropriate load sensor and verify zero balance.
Set the test speed and travel distance based on the test requirement.
Start the test, allowing the clamps to move at equal speed in opposite directions.
Record the resistance measured by the load sensor during the test.
Analyze the data to determine peel strength, tensile strength, or adhesion force.
