Spring Testers and Testing Machines
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Spring Tension and Compression Testing Machine is designed to accurately evaluate the tensile and compressive deformation, as well as the load characteristics of springs and other elastic devices. With precise control of load, deformation, and displacement, the instrument ensures high-precision measurements. It is suitable for testing springs, rubber components, reeds, and other elastic elements under specified working lengths, providing critical data for quality control, research, and development.
Standards
(1) ISO 10243 – Metallic springs – Spring testing methods.
(2) EN 13597 – Springs – Determination of tensile and compression properties.
(3) JB/T 7796-1995, JB/T 7796-2005 – Spring tensile testing machine test methods.
(4) GB/T 13634 – Calibration of dynamometers for testing machines.
(5) JIS B7738-1993 – Spiral spring pressure and tension testing machine.
Parameters
| Parameter | Specification |
|---|---|
| Force measurement range | 1%–100% FS |
| Test speed | 0.5–500 mm/min |
| Displacement stroke | 170 mm |
| Spring free length | 170 mm |
| Disc diameter | 50 mm |
| Measurement units | N, kgf, lbf, ozf |
| Power supply | AC 220V ±10%, 50Hz |
| Operating temperature | 20 ±10℃ |
| Transport temperature | -27℃ to +70℃ |
