ISO 8092 Voltage Drop Tester for Automotive Wire Connectors
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Voltage Drop Tester for Automotive Wire Connectors is designed to measure the voltage drop across connection interfaces in automotive electrical systems. You can use it to evaluate the electrical performance and contact quality of connectors, terminals, and wire harness assemblies, ensuring reliable conductivity and compliance with automotive standards.
Standards
(1) ISO 8092-1 to ISO 8092-4 – Road vehicles wiring harness connectors
(2) QC/T 417.1–417.5-2001 – Automotive wire harness connector standards
(3) Other relevant automotive electrical testing standards
Parameters
| Parameter | Specification |
|---|---|
| Input Voltage | AC 220 V ±10%, 50 Hz |
| Working Current (DC) | 0–100 A adjustable (optional: 5A, 10A, 20A, 50A, 100A, 200A, 500A, 1000A) |
| Current Output Mode | Constant current |
| Voltage Drop Range | 0–20 V |
| Measurement Ranges | 0–200 mV / 0–2 V / 0–20 V |
| Display Resolution | 0.01–199.99 mV / 0.1–1999.9 mV / 1–19999 mV |
| Power | 3200 W |
| Maximum Output Voltage | 32 V |
Application
This tester is suitable for:
(1) Measuring voltage drop at connector interfaces such as plug pins and terminals.
(2) Evaluating contact resistance performance in automotive wire harnesses.
(3) Quality inspection of non-rewirable plugs and connection leads.
(4) R&D and validation testing of automotive connectors and electrical components.
Features
(1) High-Current Output – Adjustable DC current output supports a wide testing range for different connector specifications.
(2) Micro-Voltage Measurement – High-precision measurement enables accurate detection of small voltage drops.
(3) Constant Current Mode – Ensures stable and repeatable test conditions.
(4) Multi-Range Measurement – Three voltage measurement ranges provide flexibility and accuracy.
(5) Digital Display – Clear digital tube display allows easy reading of test results.
(6) Wide Application – Suitable for connectors, terminals, and complete wire harness assemblies.
