Manikin Coughing System（Cough Simulator）
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Manikin Coughing System (Cough Simulator) is a high-precision experimental device designed to operate with a thermal manikin or a manikin head, or as an independent unit. It is used to simulate realistic human coughing conditions. By adjusting cough airflow rate, initial jet velocity, pressure, and duration, you can study aerosol particle dispersion and transmission under indoor or confined-space airflow conditions. The system provides reliable experimental data for indoor air quality studies, pollutant exposure assessment, and airborne infectious disease research.
Application
HVAC research and education, including indoor air quality evaluation, breathing and coughing exposure risk assessment in confined spaces, and cross-infection risk analysis of airborne diseases;
Medical and public health research, including simulation of pathogen-laden cough particle dispersion and airborne disease studies;
Occupational hygiene assessment, such as exposure risk evaluation of dust, PM2.5, and gaseous pollutants in workshops and factories;
Human exposure risk assessment in aerospace cabins and confined environments, including civil and military aircraft, helicopters, space stations, re-entry capsules, submarines, and deep-sea systems;
Exposure assessment and air-conditioning system optimization in vehicles and transportation systems, including buses, passenger cars, new energy vehicles, high-speed trains, subways, ships, and submarines;
Public health and military medical research in high-occupancy or densely populated environments.
Standards
GB/T 14296-2005 — Indoor Air Quality Evaluation Methods (Air Pollutant Exposure)
GB/T 18883-2022 — Indoor Air Quality Standard
ISO 7730:2005 — Ergonomics of the Thermal Environment — Analytical Determination and Interpretation of Thermal Comfort
ASTM F1291-2020 — Test Methods for Breathing and Coughing Exposure Measurement
Product Specifications
| Component | Technical Parameters |
|---|---|
| Cough Pressure | Adjustable range 0.1–4.2 bar |
| Initial Cough Airflow Velocity | Adjustable range 0.5–30 m/s |
| Cough Duration | Adjustable range 0.1–60 s |
| Cough Outlet Mode | Nasal or oral outlet; compatible with thermal manikin or manikin head |
| Aerosol Container | Venturi-type aerosol solution container supplied by the user |
| Electrical Control System | Integrated control cabinet; power supply AC 220 V / 50 Hz; maximum total power ≤ 250 W |
| Operating Environment | Temperature 10–40 °C; humidity 15–95% |
| Others | Can be used independently or with a thermal manikin/manikin head; lockable caster wheels; automatic over-pressure relief and short-circuit protection; total weight approx. 20 kg |
Features
Accurate simulation of human coughing pressure, initial airflow velocity, and duration with wide adjustable ranges;
Switchable nasal or oral coughing modes to meet different experimental requirements;
Modular design supporting standalone use or integration with a thermal manikin or manikin head;
Aerosol output compatible with external sampling devices, suitable for pathogen or particle research;
Built-in over-pressure protection and short-circuit protection for safe operation;
Mobile platform with lockable caster wheels for flexible laboratory deployment.
Accessories
| Accessory / Consumable | Specification |
|---|---|
| Cough Control Cabinet | PID control module with pressure and flow display |
| Cough Airflow Outlet Tube | Connects to thermal manikin or manikin head interface |
| Aerosol Container | Venturi-type aerosol solution container provided by the user |
| Quick-Connect Interfaces | For fast connection to thermal manikin or manikin head |
| Custom Modules | Pressure, flow, and coughing mode adjustable according to test requirements |
