Scratch Resistance Test machine
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Scratch Resistance Test Machine is a precision testing instrument designed to evaluate the scratch performance of rigid organic materials, coatings, adhesives, powder coatings, anodized materials, soft metals, plastics, and glass. It can also assess adhesive quality of protective coatings and the extreme performance of similar materials. The machine uses a balanced beam, fixed and adjustable weights, and a sample loading disc to produce controlled arcuate scratches on the test surface, providing accurate, repeatable, and quantifiable data for material development and quality control.
Application
The Scratch Resistance Test Machine is suitable for a wide range of materials and testing scenarios:
Evaluation of rigid organic materials, plastics, glass, and metals for scratch resistance
Testing coatings, adhesives, and powder coatings for durability and adhesion quality
Assessment of furniture surfaces, countertops, and high-pressure laminates
Comparative studies of protective coatings or similar materials under controlled loading
Specific testing product: Scratch Resistance Test Machine
Standards
The instrument is designed to comply with major international and national standards:
GB/T 17657‑2022 – Test methods for performance of wood-based panels and surface finishes
GB 4943.1 – Information technology equipment – Safety, Part 1: General requirements (Clause 2.10.6.6)
GB 4706.1 – Household and similar electrical appliances – Safety, Part 1: General requirements (Clause 21.2)
AS/NZS 2924.2 – Kitchen countertops and surface materials, Part 2: Abrasion and scratch resistance
ASTM C217 – Test method for abrasion resistance of ceramic glazed tiles
BS EN 438‑2 – High-pressure laminates (HPL) – Physical and mechanical properties, Part 2: Test methods
BS EN 13310 – Kitchen countertops and surface materials – Performance requirements
BS EN 14323 – Furniture surface scratch resistance, wear resistance, and chemical durability testing
DIN 68861‑4 – Furniture surfaces – Mechanical properties, Part 4: Scratch resistance
DIN 53799 – Plastics – Determination of hardness (scratch/indentation method)
Parameters
| Item | Details |
|---|---|
| Control System | PLC + Windows system |
| Operation Interface | 12-inch color industrial computer, embedded, Chinese/English switchable |
| Printing Function | WiFi connection to printer |
| Drive | Stepper motor with gearbox |
| Force Weights | Standard: 5N, 6N, 7N, 8N, 10N (other specifications optional) |
| Test Speed | Factory preset 5 r/min, adjustable 0–60 r/min |
| Scratch Spacing | Adjustable |
| Sample Size | 100 × 100 mm, center hole 6.5 mm |
| Scratch Tip | Standard diamond needle, optional 4.8R or 2.5R |
| Speed Display | Adjustable on industrial computer |
| Machine Dimensions | 550 × 310 × 520 mm |
| Power Requirement | 220V, 60A |
