High Precision Wire Winding Strength Tester ASTM International
Get a quote:
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1) GB/T 2611-2007 – Testing Machine General Technical Requirements.
(2) ISO 7800:1984 – Test Method for Unidirectional Torsion of Metal Wires.
(3) ISO 9649:1990 – Test Method for Bidirectional Torsion of Metal Wires.
(4) GB/T 3428-2002 – Zinc-Coated Steel Wire for Overhead Stranded Wire: Winding Test – Torsion Test.
(5) GB/T 239-1999 – Torsion Test of Metal Wire.
(6) GB/T 2979-2020 – Metal Materials Wire Winding Test Method.
(7) ASTM and JIS standards related to torsion and winding testing of metallic materials.
Features
(1) Dual functionality: performs both torsion and winding tests on a single machine.
(2) Provides comprehensive evaluation of wire mechanical properties.
(3) Compliant with multiple national and international standards.
(4) Streamlined testing process, improving efficiency compared to separate machines.
(5) Controlled testing parameters for repeatable and reliable results.
(6) Supports quality assurance in production and R&D applications.
(7) Adjustable sample setup to accommodate various wire diameters and lengths.
Parameters
| Parameter | Specification |
|---|---|
| Torsion sample size | Diameter 1–10 mm |
| Winding sample size | Diameter 1–6 mm |
| Distance between two plus heads | 0–500 mm, adjustable |
| Twisting/Winding speed | 0–2.0 r/s, adjustable, error <±10% |
| Power supply | AC 220V ±10%, 50 Hz |
Accessories
(1) Main testing machine
(2) Sample holders for torsion and winding tests
(3) Adjustable clamps and positioning rods
(4) Power cable
(5) User manual
