Safety Helmet Impact and Penetration Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Safety Helmet Acceleration Impact and Penetration Tester is a specialized testing machine designed to evaluate the protective performance of safety helmets. It measures a helmet’s resistance to impact and penetration under controlled conditions, recording parameters such as peak acceleration and force to ensure compliance with safety standards.
Application
The Safety Helmet Acceleration Impact and Penetration Tester is used to evaluate the impact resistance performance of safety helmets and to assess their protective capabilities.
Standards
Complies with the latest GB/T 2812-XXXX standard testing requirements.
Impact Test Technical Specifications
| Parameter | Specification |
|---|---|
| Base | Made of reinforced concrete with a mass not less than 500 kg |
| Numerical analysis system | Composed of a force sensor, single-axis acceleration sensor, data processing, display, and recording units; capable of force measurement impact tests |
| Overall machine height | Approximately 4.2 meters |
| Impact hammer | Weight 5.0 ± 0.1 kg, hemispherical impact surface, radius 50 ± 1 mm, material stainless steel |
| Impact height | 1000 ± 5 mm |
| Force sensor (specification) | Measurement range 0–20000 N, minimum frequency response 5 kHz |
| Force sensor inclusion | Force sensor included |
| Impact anvil | Flat anvil (diameter 130 ± 3 mm, thickness ≥ 15 mm), hemispherical anvil radius 48 ± 1 mm, hardness not less than HRC50 |
