Guide pin anchoring force tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
This instrument is suitable for a variety of medical and surgical applications, including:
(1) Mammary positioning wires for breast surgery – ensuring stability during preoperative procedures.
(2) Guide needles used in tumor localization – verifying anchoring effectiveness.
(3) Surgical R&D – testing new positioning wire or guide needle designs.
(4) Quality control in manufacturing – confirming the reliability of disposable guide needles and positioning filaments.
(5) Preclinical trials – simulating in-tissue performance of positioning devices.
Standards
The device is designed to meet the following standards:
(1) YY/T 0880-2013: Disposable Breast Positioning Wire and Guide Needle (China)
Optional international reference standards for extended compliance:
(2) ISO 10555-1: Sterile single-use intravascular catheters – General requirements
(3) ASTM F2084: Mechanical testing for medical guidewires
Features
(1) Accurately measures anchoring force to ensure clinical reliability.
(2) High-precision force sensor with hardware and software protection.
(3) Adjustable test speed and distance for flexible simulation.
(4) Built-in printer for immediate recording of test results.
(5) USB connectivity for data storage and export.
(6) Durable fixture made of high-quality 304 stainless steel.
(7) Simple operation with real-time force monitoring.
Parameters
| Parameter | Specification |
|---|---|
| Tensile force range | 0 – 20 N, accuracy ±1%, resolution 0.01 N |
| Test time | 1 – 999 s, error ±0.5 s |
| Test speed | 10 mm/min, 50 mm/min, 100 mm/min |
| Distance adjustment | 10 – 50 mm, adjustable |
| Force sensor | High-precision, with hardware/software protection |
| Fixture | 304 stainless steel |
| Force measuring mechanism | Built-in |
| Printer | On-board micro printer |
| Data storage | USB compatible, export to computer |
| Machine power | 70 W |
| Power supply | AC 90–240 V, 50 Hz |
Accessories
(1) Main test unit – 1 set
(2) USB storage device – 1 set
(3) Micro printer paper – 1 roll
(4) Operation manual – 1 set
(5) Optional fixtures/adapters for different guide needle diameters
