Rolling load tester/ Rolling Load Durability Tester / Material Rolling Load Tester
Standard
- EN 1569: Determines rolling load resistance of synthetic sports surfaces (e.g., PU, PVC, rubber).
- EN 14904: Tests performance of multi-sport indoor flooring under repetitive mechanical stress.
- DIN 18032-2: German standard for impact attenuation and deformation recovery in athletic facilities.
Product Advantages
1. Universal Compatibility
- Sample Thickness Flexibility: Tests materials from 2mm to 50mm (flooring, shock pads, seams).
- Adjustable Load Range: 50N to 500N customizable for basketball, volleyball, and multi-purpose courts.
2. Automated Precision
- Speed & Cycle Control: Programmable 1–10 cycles/minute with auto-pause at set intervals.
- Self-Leveling Wheel: Maintains 0.5mm contact consistency across uneven seams.
3. Unobstructed Visualization
- High-Clarity Enclosure: Polycarbonate dome with anti-fog coating for 360° process monitoring.
- LED Task Lighting: Shadow-free illumination for residual indentation inspection.
4. User-Centric Design
- Plug-and-Play Calibration: Pre-loaded EN 1569 protocols with touchscreen load adjustment.
- Ergonomic Access: Sliding front panel for quick sample changes.
5. Regulatory Compliance
- CE & TÜV Certified: Meets EU machinery directives for laboratory equipment.
- Audit-Ready Reporting: 21 CFR Part 11 compliant data logging.
Product Features
- Rolling System:
- Hardened Steel Wheel: 75mm diameter with 20° chamfer for seam simulation.
- Pneumatic Load Application: ±1N accuracy via digital pressure regulator.
- Control Panel:
- 7” TFT touchscreen with real-time cycle counter and load visualization.
- USB/Ethernet ports for PC connectivity and remote diagnostics.
- Safety Systems:
- Emergency stop with E-Stop loop monitoring.
- Overload protection at 110% of rated capacity.
- Software Suite:
- FloorDur Pro™: Auto-calculates deformation recovery (DIN 18032-2) and residual indentation.
- Cloud Sport: Remote monitoring for global R&D teams.
- Illumination:
- Adjustable LED array (3,000–6,500K color temperature).
- Auto-dimming function for operator comfort.
Technical Parameters
| Specification | Details |
|---|---|
| Load Range | 50N to 500N (adjustable in 1N increments) |
| Wheel Diameter | 75mm (EN 1569 compliant) |
| Cycle Speed | 1–10 cycles/minute (0.1 cycle resolution) |
| Sample Thickness | 2mm to 50mm (0.1mm resolution) |
| Power Supply | 220V/50Hz (110V/60Hz available) |
| Dimensions (W×D×H) | 600mm × 500mm × 1,200mm |
| Weight | 80 kg (net) |
Accessories & Options
- Standard Kit:
- EN 1569-compliant steel rolling wheel.
- Calibration weight set (50N–500N).
- Software Add-Ons:
- Batch Processor: Queue 24/7 unattended testing.
- API Integration: Connect to MATLAB/Python for custom analytics.
- Safety Upgrades:
- Explosion-proof enclosure for solvent-resistant testing.
- HEPA filtration for particle-sensitive labs.
- Calibration Services:
- Annual recalibration with NIST-traceable certificate.
- Consumables:
- 10 × Replacement polycarbonate dome panels.
- 1L Silicone lubricant for high-cycle testing.
