Photovoltaic module wire tube bending testing machine
Standard
IEC 61730-2:2004: Photovoltaic (PV) Module Safety Qualification – Requirements for Testing
CE Certification(Conformité Européenne)
Product Advantages
IEC 61730-2 Compliance
120 Hz Max Frequency: Simulates 20+ years of cable flexing in 1.000 hours.
1–9.999s Timing: Customizable test durations for accelerated life testing.
Precision Control
0.1 Hz Resolution: Ensures repeatable bending cycles per IEC standards.
Auto-Stop at Failure: Immediate cycle interruption during conduit cracking.
Energy Efficiency
100W Power Consumption: Low-energy servo motor design.
Sleep Mode: Auto-powers down between test sequences.
Safety First
Emergency Shutoff: Dual redundant safety circuits with E-stop button.
Overload Protection: 150% max torque cutoff for delicate wires.
User-Centric Design
7” HD Touchscreen: Multi-touch gestures for live force-displacement graphing.
Voice-Guided Setup: Step-by-step audio prompts for operators.
Product Features
Quick-Change Fixtures: Adapts to 2–20 mm diameter PV cables/conduits.
Dynamic Force Feedback: 0.1N resolution load cell with real-time bending angle display.
Self-Calibrating System: Auto-tare and linearity checks before each test.
Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
Data Logging: USB/Ethernet export of test cycles, peak forces, and failure points.
Technical Parameters
| Parameter | Specification |
|---|---|
| Frequency Range | 0–120 Hz (adjustable) |
| Spindle Speed | N RPM = Frequency Hz / 60 |
| Timing Range | 1–9.999 seconds (1–166.65 minutes) |
| Force Resolution | 0.1N (10 kgf max capacity) |
| Bending Angle Accuracy | ±1° (via rotary encoder) |
| Power Supply | 220V AC, 50/60Hz (single-phase) |
| Dimensions | 500mm (W) × 400mm (D) × 600mm (H) |
| Weight | 45 kg (net) / 60 kg (gross) |
Accessories Included
Testing Kit:
10x conduit clamps (2–20 mm range).
5x calibration weights (1N–10N).
Software Suite:
License key forBendTest Pro(Windows/macOS).
1-year free access to cloud-based fatigue analysis tools.
Calibration & Safety:
NIST-traceable torque wrench.
Insulated gloves (Class 0. 3 pairs).
Maintenance Kit:
Spare drive belts and bearings.
Machine cleaning solution (non-corrosive).
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for IEC/UL/ISO standards.
