Burning Manikin System,Burn Test Manikin for sale
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The burning manikin system is used to test the overall thermal protection performance of protective clothing.Complete combustion manikin system, which consists of combustion chamber, burning manikin and gas control system and other components.
Standard:
EN ISO 11612. EN ISO 11611. ISO 13506. EN469:2005.
ISO13506-1：Protective clothing against heat and flame- part1: Test method for complete garments-Measurement of transferred energy using an instrumented manikin
ISO13506-2：Protective clothing against heat and flame- part2: Skin burn injury prediction- Calculation requirements and test cases
ASTM F1930：Standard test method for evaluation of flame-resistant clothing for protection against fire simulations using an instrumented manikin
GB8965.1
GBT23467
Principle:
The burning manikin system is composed of:
1. computer combustion dummy;
2. thermal sensor group;
3. flame generator;
4. computer control module;
5. data acquisition and processing module;
6. burn analysis module.
Parameters:
Dimensions:
The installation requires a laboratory space 14 meters long, 6 meters wide, and at least 6 meters high.
Weight:
2000 kg
Components:
Thermal sensor
Combustion flame array
Gas supply system
Combustion chamber
Data acquisition system and test software
