Spray Aerosol Ignition Distance Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Product Description
Conforms to UN Recommendations on the Transportation of Dangerous Goods - Manual of Tests and Criteria 31.4 Ignition Distance Test for Spray Aerosols and GB/T 21630-2008 Test Method for Ignition Distance for Dangerous Goods Spray Aerosols.
Standards
GB/T 21630-2008
GAT536
NY/T 1860
Product Features
1. It adopts an embedded processor and the Windows CE operating system.
2. With an 8 - inch liquid - crystal touch screen, it can display the test status in real - time.
3. It integrates two working modes: the "standard mode" and the "custom mode".
4. The aerosol sprays automatically, and the aerosol can clamping device can automatically make the can stand upright or turn it upside - down.
5. The nanosecond - level photosensitive sensor detection module automatically detects whether the spray is burning.
6. Driven by a hybrid stepping motor and equipped with an optical encoder, it enables precise positioning of the measurement position.
7. It uses a spark lighter as the ignition source, producing a blue - colored non - glowing flame with a height of 4 - 5 cm, and the flame height is adjustable.
8. The test process is fully automated, requiring no manual intervention. It supports functions such as parameter setting, data storage, and report viewing.
9. The dedicated fire - proof accordion cover can effectively prevent equipment contamination.
10. It is equipped with a temperature and humidity module to monitor the temperature and humidity of the test environment in real - time.
Technical parameters
|
Operating Environment |
(5~40)℃, <85%RH |
|
Ambient Temperature Measurement Range |
(-10~+60)℃ |
|
Ambient Temperature Measurement Accuracy |
±0.5℃ |
|
Ambient Humidity Measurement Range |
(5~95)%RH |
|
Ambient Humidity Measurement Accuracy |
±5.0%RH |
|
Flame Detection Response Time |
≤6ms |
|
Flame Detection Distance |
(15~90)cm |
|
Positioning Accuracy |
±1mm |
|
Minimum Pressing Duration |
5s |
|
Ignition Method |
Gas Igniter |
|
Aerosol Tank Positioning |
Aerosol canisters can be turned over automatically |
|
Compatible Spray Tank Dimensions |
Height (120~400)mm, Diameter (30~80)mm |
