Vibration Table
Standard
- ASTM D999: Vibration testing of shipping containers and packaged products.
- TAPPI T819: Corrugated box performance under simulated transport vibrations.
- ISO 2247: Packaging—Complete, filled transport packages—Low-pressure vibration test.
- ISTA 1A/2A: Standardized protocols for e-commerce and parcel shipping validation.
Product Advantages
1. Universal Testing Compliance
- Multi-Standard Certification: Pre-configured profiles for global logistics requirements.
- Regulatory Confidence: Meets Amazon, FedEx, and UPS carrier testing specifications.
2. Realistic Transport Simulation
- Circular Vibration Mode: Mimics truck, rail, and aircraft vibration profiles.
- 2–5 Hz Frequency Sweep: Replicates road roughness to port handling impacts.
3. User-Centric Operation
- Digital Control Panel: LCD speed display with 0.1 Hz resolution.
- Auto-Stop Counter: Programmable cycle limits (1–999,999 counts).
4. Adaptable Design
- Modular Payload Capacity: 100–8,000 lbs (45–3,628 kg) load range for parcels to pallets.
- Ergonomic Loading: Low-profile front ramp (8° incline) for forklift-free sample placement.
5. Industrial Durability
- Abrasion-Resistant Deck: 12mm steel plate with diamond-hard coating.
- Maintenance-Free Drive: Sealed motor system with 10,000-hour MTBF rating.
Product Features
- Vibration System:
- Synchronous Motor: 3-phase AC drive with 0.1 Hz frequency resolution.
- Circular Orbit: 25.4mm (1”) amplitude for realistic transport simulation.
- Control Interface:
- 4.3” TFT touchscreen with pre-loaded ASTM/ISTA protocols.
- USB port for test data export and firmware updates.
- Safety Systems:
- Emergency stop with E-Stop loop monitoring.
- Overload protection at 110% of rated capacity.
- Deck Configuration:
- Adjustable rear bumper (0–300mm height adjustment).
- Removable front guard for unobstructed sample access.
- Mobility:
- Heavy-duty casters with floor locks for stationary operation.
- Forklift pockets for warehouse relocation.
Technical Parameters
| Specification | Details |
|---|---|
| Frequency Range | 2–5 Hz (0.1 Hz increments) |
| Max. Payload | 100–8,000 lbs (45–3,628 kg) |
| Deck Size | 1.2m × 1.2m (standard) |
| Amplitude | 25.4mm (1”) circular orbit |
| Power Supply | 220V/50Hz or 380V/3-phase (field-configurable) |
| Dimensions (W×D×H) | 1,500mm × 1,500mm × 800mm (standard) |
| Weight | 450 kg (net) |
Accessories & Options
- Load Capacity Expansion:
- Reinforced deck frames for 4,000–8,000 lbs payloads.
- Distributed load spreaders for palletized testing.
- Software Add-Ons:
- VibLog Pro™: Real-time FFT analysis and vibration spectrum logging.
- Cloud Logistics: Remote monitoring for global supply chain teams.
- Calibration Services:
- Annual recalibration with ISO 17025-accredited certificate.
- Safety Upgrades:
- Seismic-rated anchoring system for high-risk zones.
- Explosion-proof enclosure for hazardous environments.
- Consumables:
- 1L High-temperature lubricant for motor maintenance.
- 5 × Replacement deck anti-slip mats.
