Thermal cycle wet freezing testing machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
IEC 61215: Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
UL 1073: Standard for Safety for Enclosures for Electrical Equipment
ISO 16750-4: Road Vehicles – Environmental Conditions and Testing for Electrical and Electronic Equipment
CE Certification(Conformité Européenne)
Product Advantages
Extreme Environmental Simulation
-40°C to +85°C Range: Replicates Arctic cold to desert heat in a single chamber.
98% RH Humidity Control: Tests condensation resistance for marine/tropical applications.
Ultra-Stable Performance
±1°C Temperature Stability: Ensures consistent testing across 1.000+ cycles.
≤±2°C Uniformity: Patented airflow design eliminates hot/cold spots.
Rapid Transient Response
IEC 61215-Compliant Ramps: 10°C/min heating, 7°C/min cooling (customizable).
Auto-Tuning PID: Adapts to payload changes in real-time.
Energy Efficiency
40% Lower Power Consumption: Advanced insulation and heat recovery systems.
ECO Mode: Auto-powers down during stabilization phases.
Safety First
Dual Overload Protection: Thermal cutout and current-limiting circuit breaker.
Door Interlock System: Prevents accidental chamber access during testing.
Product Features
Dual-Chamber Design: Isolated wet/dry zones for simultaneous multi-condition testing.
10” Touchscreen HMI: Preloaded IEC/UL test profiles with customizable hold times.
Remote Monitoring: Wi-Fi/Ethernet connectivity with SMS/ alerts.
Self-Diagnostics: Real-time sensor health checks and error logging.
Glovebox Compatibility: Oxygen/moisture control for sensitive electronics testing.
Accessories Included
Testing Kit:
4x universal sample racks (adjustable for batteries/PV modules/PCBAs).
10x humidity sensor calibration capsules.
Software Suite:
License key forEnviroTest Pro(Windows/Linux).
1-year free access to cloud-based test report generator.
Calibration & Safety:
NIST-traceable temperature/humidity logger.
Emergency eyewash station (portable).
Maintenance Kit:
Spare heating elements and refrigerant filters.
Chamber cleaning solution (non-corrosive).
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for IEC/UL/ISO standards.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | -40°C to +85°C (operational) |
| Temperature Fluctuation | ≤±1°C |
| Temperature Deviation | ≤±1°C (at steady state) |
| Temperature Uniformity | ≤±2°C (empty chamber) |
| Heating Rate | 10°C/min (typical, configurable) |
| Cooling Rate | 7°C/min (typical, configurable) |
| Humidity Range | 30%–98% RH (non-condensing) |
| Humidity Deviation | ±3% FS (at 85% RH ±2%, 90% RH ±2%) |
| Chamber Volume | 500L (standard), expandable to 1.500L |
| Power Supply | 380V/415V 3-phase, 50/60Hz |
| Dimensions | 1.200mm (W) × 1.800mm (D) × 2.000mm (H) |
| Weight | 800 kg (net) / 1.200 kg (gross) |
