Textile Acid Printed Fabric Surface Wool Adhesion Meter
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
ISO 9073-4: Textile flatness measurement
ASTM D3884: Abrasion resistance correlation
AATCC 124: Appearance after repeated home laundering
GB/T 3917.2: Chinese fabric evenness standard
Features
1. An AI- and machine vision-based device that highly integrates objective fabric performance evaluation.
2. Replaces manual grading (ISO 07768:2009. GB13769:2009. AATCC124:2014) with advantages including objectivity, speed, and reproducibility; CNAS-accredited.
3. Features simplified operation and high automation.
4. Clean software interface with intuitive controls; one-click grading after region selection.
5. Comprehensive metric system captures detailed visual characteristics for enhanced analysis.
Translated with DeepL.com (free version)
Parameters
| Parameter | Specification |
|---|---|
| Scanning Resolution | 0.1 mm × 0.1 mm grid mapping |
| Thickness Measurement Range | 0.05–10 mm (±0.5% accuracy) |
| Surface Roughness Detection | 0.1–100 μm Ra (ISO 4287) |
| Weave Flatness Index | Calculated automatically |
| Sample Size | Up to 1000 × 1000 mm (adjustable) |
| Light Source | 400–700 nm RGB LED array |
| Data Output | 3D topography map + statistical CSV |
| Dimensions (L×W×H) | 1500 × 800 × 1200 mm |
| Weight | ~180 kg |
| Power Supply | AC 220V ±10%, 50/60 Hz |
Accessories
Vacuum clamping table for sample mounting
Reference calibration plates
Protective anti-static mat
Software package for analysis and reporting
Power cable and operation manual
Test Procedures
Clamp the fabric sample on the vacuum table, ensuring no folds or wrinkles.
Select the scanning mode (static or dynamic) via the control panel.
Initiate full-area 3D scanning; system captures thickness, roughness, and weave irregularities.
Review real-time heatmaps and defect detection alerts.
Export analysis data for reports or historical comparison.
After testing, clean scanning surface and sample holder; avoid dust accumulation.
Periodically recalibrate using NIST-traceable reference plates to maintain accuracy.
