Features and Benefits
1. STD UV-SI-260 is widely used in UV aging test, which can realize the comprehensive test of UV, temperature, humidity and water.
2. The uv aging test equipment is equipped with 8 UV lamps, and the current of the lamps can be displayed, mainly to display the service life of the lamps, which is convenient for users to replace the lamps in time.UVA-340.UVB-313.UVB-351 are all supported.UV lamp power is 40W.
3. The specimens of the uv aging machine are easy to install, and 52 pieces of 75*150mm specimens can be put in at one time.Customized sample holder is also designed for irregular test pieces.
4. All uv weathering test chambers are CE and RoHS certified.
Specifications
|
Model |
STD UV-SI-260 |
|
Internal Dimension (mm) |
450*1170*500 |
|
Overall Dimension (mm) |
610*1330*1470 |
|
Specimen Holder Size(mm) |
75*150 |
|
Specimen Capacity |
56 Pieces |
|
Irradiation Source |
Fluorescent UV lamps (8) - 40 W |
|
Temperature Range |
Ambient ～ 90 ℃ ±2℃ |
|
Black Panel Temperature (BPT) |
35 ～ 80 ℃ |
|
Humidity Range |
≥95% RH |
|
Bandwidth |
290 ~ 400nm |
|
Irradiance Control |
0.3~20 W/㎡ |
|
Water Spray Cycle |
1~9999H59M (Adjustable) |
|
Distance of Specimen and lamp |
50mm |
|
Controller |
Programmable color LCD touch screen controller, Ethernet connection |
|
Water Supply System |
Automatic water supply, Water purification system |
|
Safety Device |
Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection |
|
Exterior Material |
Steel Plate with protective coating |
|
Interior Material |
SUS304 stainless steel |
Application
UV spectra is a part of sunlight spectra, causing damage to test pieces. All the specimens needed to be under UV light radiation can be tested in the UV test chamber. For example, plastics, rubber, coatings and etc. in automotive industry, aerospace, building materials. UVtesting chambers, as a type ofuv accelerated weathering tester,are also widely used in scientific laboratory conducting research on material aging and photochemistry.
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
