Shoe Sole Slip Resistance Tester
Product Introduction:
Test method for static anti-slip performance of footwear, measuring the static anti-slip performance of soles, heels or similar materials.
Reference standard:
ASTM-F609 Standard Test Method for Flat Pull Slides （HPS）
Product Advantages:
Measures Key Safety Property: Quantifies static slip resistance, a direct measure of how well footwear materials resist initial sliding on a surface.
Standard Compliant: Designed to meet standards like ASTM F609. ensuring tests are performed according to established procedures and results are comparable.
Provides Quantitative Result: Delivers an objective numerical value for the static coefficient of friction.
Controllable Test Speed: Allows adjustment of the pulling speed to comply with standard requirements.
Accurate Measurement: Designed for precise measurement of the force required to initiate slip.
Suitable for Various Footwear Materials: Applicable for testing soles, heels, and other related materials.
Product Features:
Weighted test foot or sled (likely the 2.7kg component mentioned) with a surface designed to hold the test sample (sole or heel material).
Mechanism to apply a controlled horizontal pulling force to the weighted test foot resting on the test surface.
Sensor or gauge to accurately measure the horizontal force at the exact moment the test foot begins to slide (static friction force).
Capability to calculate the static coefficient of friction (SCOF) as the ratio of the static friction force to the normal force (weight of the test foot).
Adjustable test speed (0-200 mm/min) for the horizontal pulling action.
Designed to accommodate a specific test size (16mm, likely referring to a dimension or characteristic of the test foot or contact area, though standard ASTM F609 test feet have specific materials and contact areas).
Digital display for showing test parameters and results (SCOF value).
Robust construction suitable for laboratory or quality control environments.
Technical specifications:
1. Weight: 2.7kg
2. Test speed: 0-200mm/min
3. Test size: 16mm
4. Accuracy: ±1%
5. Volume: 76*42*39cm
6. Weight: 65kg
7. Power supply: AC220V,10A
