Qinsun Xenotest 220

Standards

  • ISO 105-B02: Lightfastness testing for colored textiles.
  • AATCC TM16 (Option 3): Accelerated weathering for textiles under controlled conditions.
  • Marks & Spencer C9/C9A: Retail-specific durability protocols for apparel and home textiles.

Product Advantages

  1. Unmatched Capacity:
    • Tests38 samples simultaneously, doubling the throughput of the 150 S+ model within the same footprint.
    • Optimized for high-volume testing without compromising precision.
  2. Cost Efficiency:
    • Air-cooled designreduces energy consumption by 30% compared to water-cooled alternatives.
    • 60-liter integrated water tankminimizes refill frequency for ultrasonic humidification.
  3. Precision Control:
    • Direct adjustment of irradiance (300–400 nm), black label temperature, chamber humidity, and airflow.
    • Dual temperature control(up to 100°C) for black label and chamber, managed via fan-assisted differential regulation.
  4. User-Centric Design:
    • 220+ Model: Color touchscreen interface with multi-language support (10+ languages) and 10 programmable test presets.
    • Advanced Diagnostics: Real-time error alerts and internal data logging via storage chip.
  5. Compliance & Versatility:
    • Preconfigured for ISO and AATCC standards, with customizable end-of-test triggers (sunlight exposure, runtime, or illumination dose).

Product Features

  • Illumination System:

    • 2200W air-cooled xenon lamp tube for stable UV-A to visible light output.
    • Long-life filter technologyensures consistent spectral distribution (300–400 nm) over 1,500+ hours.
  • Sample Handling:
    • XENONSENSIV® Sample Rack: Holds 19 containers (38 textile samples) with integrated sensors for irradiance (W/m²) and black label temperature (°C) monitoring.
  • Climate Control:
    • Ultrasonic humidification with automatic water replenishment.
    • Relative humidity range: 10%–70% RH (non-condensing).
  • Connectivity:
    • Ethernet & RS232 interfacesfor data export.
    • XenoTouch Attachments: Remote monitoring, alerts, and cloud integration (Optional 1/2/3).
  • Safety & Durability:
    • UV-blocking observation window for safe sample inspection.
    • Robust construction with corrosion-resistant materials for industrial environments.

Technical Parameters

SpecificationDetails
Lamp Type 2200W air-cooled xenon arc
Exposure Area 310 cm² (48 in²)
Irradiance Control 300–400 nm, adjustable via touchscreen (220+)
Temperature Range Chamber: 30–65°C (86–149°F) / Dual: 30–100°C
Humidity Range 10%–70% RH (non-condensing)
Power Supply 230V, 50/60Hz, 25A
Dimensions (W×D×H) 900 × 750 × 1,800 mm
Weight 320 kg (705 lbs)

Accessories & Options

  1. XenoTouch 1/2/3:

    • Remote control, real-time alerts, and web-based monitoring.
  2. Dual Temperature Control Kit:
    • Simultaneous management of chamber and black label temperatures.
  3. Extended Warranty:
    • 3-year coverage for lamp, filters, and electronics.
  4. Custom Filter Sets:
    • Tailored spectral ranges for specialized textiles (e.g., UV-enhanced for outdoor fabrics).

Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
