Auto wire abrasive belt drag grinding machine
Applicable standards:
QC/T730-2005. SAE-J1128-2005. DIN 72551. IS06722. JASO D 618 and other standards
Application:
Suitable for detecting the drag resistance test of automobile wires.The abrasion resistance tester is to fix the product on the fixture at both ends, and the abrasive belt can test the product under certain load, speed and stroke. Auto Parts Test Equipment
Test sample:
Automobile wires.
Feature:
1.The cabinet is treated with electrostatic baking paint. The whole machine has reasonable design, tight structure, safe and stable operation up to standard.
2.Length can be preset, load can be superimposed, humanized design.
Main parameters:
1. Applicable wire diameter: less than 15mm
2. Sand belt length counting range :0——999999mm
3. Sand belt walking speed :1500mm/min
4. Rounded corner of sand belt support :3.5mm
5. Test voltage :24V
6. Load :20g/50g/100g/200g(2PCS)/500g/900g/1000g
7. Load support weight :65g(0.63N±0.05N)
8. Sand belt and sample Angle :29°
9. Conductive strip spacing :75mm or 150mm
10. Conductive strip width :10mm
11. Power :200VA/220V 50HZ
12. 80#, 150#, 180#, 400# sanding belt is available
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
