Voltage Drop Tester for Automotive Wire Connectors-QINSUN
The voltage drop tester for automotive wire connectors is suitable for measuring the voltage drop at similar connection interfaces such as the pins of non - rewirable plugs and the leads of connecting plugs, so as to judge the quality of the connection interfaces. It can also be used for testing the contact voltage drop of terminals in connectors and wire harnesses. It complies with the ISO 8092.1 - .4 series of standards and relevant standards such as QC/T417.1 - 417.5 - 2001 for automotive wire harness connectors.
Technical Features:
This instrument features adjustable high - current output, micro - voltage testing, and digital tube display.
Main Parameters:
1. Input voltage: AC220V + 10%, 50Hz
2. Working current (DC): 0 - 100A (optional values including 5A, 10A, 20A, 50A, 100A, 200A, 500A, 1000A) and can be adjusted arbitrarily 3. Current output mode: Constant current
4. Voltage drop range: 0 - 20V (with three voltmeters of different accuracies for 0 - 200mV / 0 - 2V / 0 - 20V). The display ranges are 0.01 - 199.99mV / 0.1 - 1999.9mV / 1 - 19999mV respectively
5. Power: 3200W, maximum output voltage: 32V
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
