Water Cooled Xenon Lamp Testing Chamber
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
| STANDARD: | Xenon Weather Test Chamber | Material: | Stainless Steel |
|---|---|---|---|
| Temp. Range: | RT-85º C | Interior Dimensions: | 500× 600×500mm(W× H× D) |
| Lamp: | 3kw Xenon Lamp | Radiation: | 500~1100w/m2± 10% |
| Highlight: |
environmental testing equipment environmental testing machine |
||
Use
Water Cooled Xenon Lamp Testing Chamberis used to determine the color fastness and aging to sunlight, weather resistance, compound color fastness to sunlight-perspiration of Geotextile, leather, leatheroid, plastic, etc, by setting various parameters of irradiance, temperature, humidity, spray to simulate natural condition in lab. Be able to control irradiance real-time, automatically inspect and compensate irradiance, temperature, humidity.
Features
1.Presetting various specifications,Custom program capability, meet diverse range of standards, including AATCC, ISO, BS, JIS etc;
2.Colorful touch screen, indicate the condition of chamber at real-time, be able to presetting irradiance, temperature (BPT, BST, chamber), humidity, and plot dynamic curve of them. The operator simply selects the required test module and test standards; English user interface, diagram indicate condition of chamber, easy to use;
3.PLC control, powerful program and storage property, save the parameters when interrupt of power supply.
4.Chamber temperature control, irradiation temperature, and heater raise the temperature, air conditioning refrigeration.
5.Custom program capability and storage for additional user-defined tests.
6.Built-in diagnostics and warnings,automatic prompt when lamp or optical filters require changing. Multi-position sensor to supervise working condition, temperature, humidity, fan, xenon lamp, and door to chamber, it makes device work properly and reliably;
7.Usedriving clutch to connect turntable and motor, it makes turntable rotate freely and put sample easily without stopping unit;
Technical parameters
Xenon lamp technical parameters temperature range RT ℃ ~ +80 ℃ light irradiance
Spectral wavelength: 290nm ~ 800nm Irradiation range of 550W ~ 1200W / ㎡,
| Temperature fluctuation | ≤ ± 0.5 ℃ |
| Temperature uniformity | ≤ 2 ℃ |
| Cooling rate | 0.7 ~ 1 ℃ / min (non-linear) |
| Heating rate | 3 ~ 5 ℃ / min (non-linear) |
| Humidity range | 30% ~ 98% R.H |
| Humidity fluctuates | 3% to 4% R.H |
| Blackboard temperature | 63 + 3 ℃ |
