8 Station Pneumatic Fatigue Test Sequencer
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
1. Product Function and Application
The 8 Station Pneumatic Fatigue Test Sequencer is a multi-channel, air-powered fatigue testing system designed to perform a wide range of cyclic durability and performance tests on mechanical assemblies.
Using pneumatic actuation with forward–release–reverse–release control, this universal tester is ideal for repetitive motion testing, endurance validation, and life-cycle evaluation of various automotive, furniture, and mechanical components.
It supports up to 8 independent or synchronized test channels, allowing simultaneous or sequential operation. Each channel can be independently configured to perform specific test actions, providing unmatched flexibility for complex multi-axis or multi-part testing.
This system is well suited for automotive seat fatigue testing, component life testing, cyclic actuation testing, and durability validation of mechanical systems.
2. System Features and Control
Independent Channel Operation – Up to 8 channels can operate independently, simultaneously, or in a synchronized sequence.
Interactive Programming Interface – Simple click-and-drag software with graphical interface for intuitive test setup.
Pressure Regulation per Channel – Each channel includes individual forward and reverse pressure regulators for precise control.
Configurable Control Logic – Sequences can be triggered by time, limit switches, or proximity sensors.
Load Cell Integration – Optional load cell converter box allows force-based control or limit switching.
Fault Detection – Limit switches can detect over-travel or fault conditions during operation.
Data Storage – Created test sequences can be saved and recalled for future use, enhancing efficiency and repeatability.
3. Technical Specifications
| Item | Specification |
|---|---|
| Test Stations | 8 independent pneumatic channels |
| Operation Modes | Independent, simultaneous, or sequential |
| Control Type | Forward–release–reverse–release pneumatic control |
| Pressure Supply | 80 PSI clean, dry compressed air |
| Power Supply | 120 VAC |
| Interface | Graphical click-and-drag software |
| Pressure Control | Individual forward/reverse regulators for each channel |
| Sensors | Compatible with limit switches and proximity sensors |
| Force Measurement | Optional load cell converter per channel |
| Enclosure | Roll-around console cabinet for mobility |
| Programmability | Fully configurable test sequences with save/load capability |
