Tumble dryer
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Tumble Dryer is designed for textile testing applications, specifically for home laundering and drying procedures. It provides a controlled drying environment for textile samples, ensuring accurate and repeatable results. The dryer is suitable for laboratory use in compliance with national and international textile testing standards, offering precise temperature control, stable drum rotation, and consistent drying performance.
Application
Used in textile laboratories for drying samples following home laundering and drying procedures, including domestic textiles, garments, and other fabrics requiring standardized drying tests. Ideal for evaluating dimensional stability, shrinkage, and fiber integrity after washing.
Standards
GB/T 8629: Domestic textile drying procedures
ISO 6330: Textiles — Domestic washing and drying procedures for textile testing
Feature
(1) Front-loading design with horizontal drum for uniform drying.
(2) Drum diameter of 58 cm ±1 cm with three lifting pieces spaced 120° for even tumbling.
(3) Controlled outlet air temperature below 80°C to prevent fiber damage.
(4) Rated drying capacity of 5 kg suitable for standard test specimens.
(5) Stable drum speed at 50 r/min for consistent drying results.
(6) Compact, space-saving design for laboratory benchtop use.
(7) Reliable AC220V / 50Hz power supply with 1.25 kW consumption.
Technical Specifications
| Parameter | Specifications |
|---|---|
| Type | Front door loading, horizontal drum |
| Drum Diameter | φ58 cm ± 1 cm |
| Drum Speed | 50 r/min |
| Number of Lifting Pieces | 3 (spaced 120° apart) |
| Rated Drying Capacity | 5 kg |
| Controlled Outlet Air Temperature | < 80°C |
| Power Supply | AC 220V / 50Hz |
| Power | 1.25 kW |
| Dimensions (L×W×H) | 630 × 530 × 690 mm |
| Net Weight | 25 kg |
Send product request
