Solar Simulator Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Solar Simulator is a brand-new solar energy simulator that provides a completely new solar energy experience. It features highly realistic sunlight simulation, accurately mimicking the intensity and angle of sunlight at different times and seasons. Through the BBA Solar Simulator, users can experience the warmth and comfort of real sunlight.
Applications
This BBA device provides an environment close to natural sunlight. The purpose of the solar simulator is to provide a controllable indoor experimental facility for testing solar photovoltaic modules. The AAA-grade large-area steady-state solar simulator is primarily used for testing large-area photovoltaic modules, and can perform tests including maximum power testing, temperature coefficient measurement, performance under low irradiance, hot spot durability testing, and photoaging testing.
Standards
IEC 61215: Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
IEC 61646: Thin-Film Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
ISO 9060: Solar Energy – Classification of Pyranometers
UL 1703: Safety Standard for Photovoltaic Modules
CE Certification (Conformité Européenne)
Features
BBA-Grade Performance
Class B Spectral Matching: Ensures AM1.5G compliance for accurate energy rating.
Grade B Irradiance Uniformity: <5% deviation across 2.0m × 1.0m test area.
Multi-Mode Testing
STC/NOCT/Hotspot Simulation: Replicates standard test conditions, nominal operating cell temperature, and thermal runaway scenarios.
1.000 W/m² Tuneability: Adjustable irradiance for low-light performance mapping.
Stability First
Class A Transient Stability: <2% flicker during pulsed load testing.
Metal Halide Lamp Longevity: 5.000-hour lifespan with <10% lumen depreciation.
Smart Control
AI-Powered Irradiance Correction: Compensates for lamp aging in real-time.
Remote Calibration: Wi-Fi/Ethernet connectivity for ISO 17025 compliance.
Safety First
UV Filter: Blocks harmful UVC radiation during operator access.
Emergency Shutoff: Dual redundant safety circuits with GPS-enabled alerts.
Technical Parameters
|
Parameter |
Specification |
|
Irradiance Range |
200–1.200 W/m² (AM1.5G filtered) |
|
Spectral Matching |
Class B (IEC 60904-9) |
|
Uniformity |
Grade B (<5% deviation) |
|
Stability |
Class A (<2% transient flicker) |
|
Lamp Type |
Metal Halide (400 nm–1.100 nm output) |
|
Test Area |
2.000mm (W) × 1.000mm (D) |
|
Power Supply |
380V/415V 3-phase, 50/60Hz |
|
Dimensions |
2.500mm (W) × 1.500mm (D) × 2.200mm (H) |
|
Weight |
1.800 kg (net) / 2.500 kg (gross) |
