Rubbing Color Fastness Tester

Manual friction fastness tester is the most commonly used instrument for the textile industry to detect the color fastness of the fabric to dry and wet rubbing. Under certain conditions, the sample is rubbed against the standard small white cloth. Assess the degree of color transfer to the small white cloth with gray scale. The tester is equipped with crank arm, counter, stainless steel sample holder, 16mm or 25mm diameter test head (providing 9N + 10% vertical pressure).

Application

This instrument is applicable to the test of color fastness in textile, knitwear, leather, electrochemical plate and printing

Accessories and consumables:

1. Friction cloth clamping clip

2. Standard friction sandpaper

3. Small white friction cloth (AATCC/ISO standard)

4. Friction small white cloth (SDC)

5. Calibration fabric

6. Grey card (color) -ISO/BS standard

7. Grey card (stained) -AATCC standard

Standards

BS 1006 D02: Textiles—Tests for colorfastness—Part D02: Colorfastness to rubbing

ISO 105 D02 X12: Textiles—Tests for colorfastness—Part D02: Colorfastness to rubbing

AATCC 8 & AATCC 165: Standards of the American Society of Textile Chemists and Dyestuffs

GB/T 3920: Textiles—Tests for colorfastness—Colorfastness to rubbing

Feature

1. Strong Standard Compatibility

It is presumed to comply with core domestic and international testing standards such as GB/T 3920. ISO 105 X12. and AATCC 8. meeting the friction color fastness testing needs of various industries including textiles, leather, and coated materials. It is compatible with both dry and wet friction testing scenarios.

2. Precise and Controllable Test Parameters

As a professional testing device, it is likely equipped with standard friction heads (such as 16mm circular or 16mm × 25mm rectangular), applying a stable pressure of approximately 9N. Key parameters such as friction stroke and speed (e.g., 60 cycles/minute) can be precisely adjusted, ensuring the repeatability and accuracy of test data.

3. Optimized Operation and Efficiency

It may feature a single-station or multi-station design (to accommodate different testing volume requirements), utilizing an electric drive system and supporting automatic stop and alarm after a preset number of friction cycles. It is likely equipped with a simple operating interface (such as a touchscreen) for easy parameter setting and sample loading/unloading, reducing manual operation costs.

4. Durable Structure and Easy Maintenance

The machine body is likely made of high-strength materials such as aluminum alloy, and the friction moving parts use wear-resistant materials, ensuring smooth and quiet operation. The design emphasizes ease of maintenance, requiring no frequent or complex maintenance, extending the equipment's lifespan.

Parameters

Maxheadtravel:	104mm
Headpressure	9N
Headdimensionround	16mm
Counterrange	1~99999times
Instrumentsize	700*240*340mm
Weight	15Kg
